38 WXZ468RMP
280-8262-00
English
Radio section
Tuning System: PLL synthesizer tuner
Receiving Frequencies:
FM : 87.5 to 108 MHz (0.05 MHz steps)
MW : 531 to 1602 kHz (9 kHz steps)
LW : 153 to 279 kHz (3 kHz steps)
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (±1 dB):
10 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
90 dB
Dynamic Range (1 kHz):
90 dB
Harmonic Distortion:
0.01%
Channel Separation (1 kHz):
75 dB
9. SPECIFICATIONS
Audio
Output Power:
4 ✕ 27 W (DIN 45324, +B=14.4V)
Continuous Average Power Output:
17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (60 Hz/80 Hz/120 Hz):
+14 dB, -12dB
Treble Control Action (8 kHz/12 kHz):
±12 dB
9 Band-G-EQ (63Hz to 16kHz)
1 oct step GAIN ± 12dB
Line Output Level (CD 1 kHz):
1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption:
Less than 15 A, 3A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Main unit:
2.3 kg
Dimensions / Main unit:
178 (W) ✕ 100 (H) ✕ 160 (D) mm
Note:
• Specifications and design are subject to change without notice for further improvement.
