3. NOMENCLATURE
Notes:
• Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 5 (unfold).
[CD SLOT]
•
CD insertion slot.
IR-Receiver
•
Receiver for remote control unit. (Operating range:
30° in all directions)
[Q] button
•
Ejects a disc.
•
Press and hold for 1 second or longer to eject all
discs.
[DISP] button
•
Switches the display indication (main display, title dis-
play, and clock display).
•
Press and hold for 1 second or longer to switch to the
display adjust mode.
[VOLUME] knob
•
Turn to adjust the volume.
[RDM] button
•
Performs random play while in the CD/MP3 mode.
•
Press and hold for 1 second or longer to perform all
random play.
[RPT] button
•
Repeats play while in the CD/MP3 mode.
•
Press and hold for 1 second or longer to perform all
repeat play.
[SOURCE] knob (PUSH POWER)
•
Turn to switch the operation mode among the radio
mode, etc.
•
Press to turn on the power.
•
Press and hold for 1 second or longer to turn off the
power.
[SCN] button
•
Performs scan play for 10 seconds of each track
while in the CD/MP3 mode.
•
Press and hold for 1 second or longer to perform all
scan play.
[TITLE] button
•
Switches the titles.
•
Press and hold for 1 second or longer to input or
scroll the title.
[DIRECT] buttons
•
Stores a station into memory or recalls it directly
while in the radio mode.
•
Selects the disc.
Names of the Buttons and their Functions
[A-MODE] knob (PUSH G.EQ)
•
Turn to select the folder. (MP3/WMA disc only)
•
Press to switch to the audio mode (LPO, D-Z LEVEL,
G.EQ EDIT, BASS, TREBLE, BALANCE, FADER).
•
Press and hold for 1 second or longer to turn on or off
the G.EQ.
[D-Z] button
•
Selects one of the 3 types of sound characteristics
preset in memory.
[ADJ] button
•
Switches to the adjust mode.
•
Press and hold for 1 second or longer to switch to the
RDS mode. (Radio, DAB mode only)
[SEARCH] knob (PUSH PS/AS, , ENT)
•
Turn to select a station while in the radio mode or se-
lects a track while in the CD/MP3 mode.
•
Turn for 1 second or longer to switch the fast-forward/
fast-rewind.
•
Press to perform preset scan in the radio mode.
Press and hold for 2 seconds or longer to perform
auto store.
•
Press to play or pause a CD while in the CD/MP3
mode.
[TA] button
•
TA (Traffic Announcement) on and off.
[BAND] button
•
Switches the band.
•
Press and hold for 1 second or longer to switch seek
or manual tuning.
•
Press and hold for 1 second or longer to switch the
track type to play in the CD/MP3 mode.
[SPE/ANA] button
•
Switches the spectrum analyzer pattern (Scan, Pat-
tern 1 to 7, Off).
[LOAD] button
•
Insets a disc.
•
Press and hold for 1 second or longer to insert two or
more discs.
Main unit / Appareil principal / Hauptgerät / Apparecchio principale
Hoofdtoestel / Unidad principal / Huvudenhet / Unidade principal
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Hinweis: Bitte diese Seite ausfalten und beim Lesen der einzelnen Kapitel die Frontdiagramme beachten.
Nota: Assicurarsi di aprire questa pagina e fare riferimento a questi diagrammi quando si legge ciascun capitolo.
Opmerking: Vouw deze pagina uit en zie tevens de afbeeldingen van het voorpaneel tijdens het doorlezen van de volgende hoofdstukken.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
Observera: Vik ut denna sida för att kunna se figurerna över bilstereons framsida medan du läser de olika kapitlen.
Nota: Certifique-se de abrir esta página e consulte os diagramas frontais conforme realiza a leitura de cada capítulo.
●When the CD/DVD changer is
connected
∗
For details, see the section “CD Changer Opera-
tions”. For the DVD changer, refer to the Owner’s
Manual provided with the DVD changer.
[DISP] button
• Switches the display indication (main display, title dis-
play, and clock display).
[RDM] button
•
Performs random play.
•
Press and hold for 1 second or longer to perform
disc random play.
[RPT] button
• Performs repeat play.
• Press and hold for 1 second or longer to perform
disc repeat play.
[SCN] button
• Performs scan play for 10 seconds of each track.
• Press and hold for 1 second or longer to perform disc
scan play.
[TITLE] button
• Switches the titles.
• Press and hold for 1 second or longer to input or scroll
the title. (only CD changer)
[DIRECT] buttons
• Selects the disc.
[SEARCH] knob (PUSH PS/AS, , ENT)
• Turn to repeat or advance a track when listening to a
disc.
• Turn for 1 second or longer to switch the fast-for-
ward/fast-rewind.
• Press to play or pause a CD or DVD.
Major Button Operations When External Equipment is
Connected to This Unit
2.
CONTROLS / LES COMMANDES / REGLER / CONTROLLI
REGELAARS / CONTROLES / KONTROLLER / CONTROLOS
●When the TV/DAB is connected
∗ For details, see the section “TV opera-
tions” or “Digital Radio/DAB operations”.
[TA] button
• Sets the TA (Traffic Announcement) standby mode in
the DAB mode. (This function is only DAB tuner.)
• Press and hold for 1 second or longer to turn on or off
the INFO mode. (This function is only DAB tuner.)
[SEARCH] knob (PUSH PS/AS, , ENT)
• Turn to select a station in the TV mode.
• Press to perform preset scan in the TV mode.
• Press and hold for 2 seconds or longer to perform
auto store.
• Press to perform service scan while in the DAB mode.
[BAND] button
• Switches the band.
• Press and hold for 1 second or longer to switch seek
or manual tuning.
[DIRECT] buttons
• Stores a station into memory or recalls it directly.
[ADJ] button
• Press and hold for 1 second or longer to switch the TV
picture mode or VTR (external) picture mode.
• Press and hold 1 second or longer to switch to the
RDS mode. (radio, DAB mode only)
