Atlantic INGENIO 50 [7/36] Installation

INSTALLATION

1. PRODUCT FIXATION

See “General Warnings” N°.1 to N°.6

For product installation, refer to drawings section 1 page.2.

2. HYDRAULIC CONNECTION

See “General Warnings” N°.10 to N°.14

For hydraulic connection, refer to drawings section 2 page 3.

- It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the

hot water outlet is to be carried out with a cast iron or steel sleeve or a dielectric connector, to

avoid corrosion of the pipe (direct contact iron / copper). The use of brass fittings is prohibited.

- Always install a new safety device on the cold water pipe of the water heater, which comply with

the standards (EN 1487 in Europe), with a pressure of 7 or 9 bars (0.7 or 0.9 MPa) according to

the nominal pressure, with diameter 1/2".

- CAUTION: Do not use the safety valve included in this packaging in France (home country and

French overseas)

3. ELECTRICAL CONNECTION

For electrical connection, refer to drawings section 3 page 4.

- The water heater can be connected and operated only on AC 230V. Connect the heater with a

rigid cable with conductors 2,5mm ². Use a standardised channeling (rigid or flexible conduit) until

the calibrated housing cover.

- Directly connect devices with a cable or plug. In France, a product with plug is strictly prohibited

and cannot be sold and installed.

- Always connect the earth conductor of the cable to the earth ground wire or connect the earth

conductor to the appropriate terminal identified by the symbol . This connection is compulsory

for safety reasons. The earth wire green - yellow must be longer than those of phases. The

installation must be equipped, upstream of the appliance, with a bipolar cut-out device (minimum

contact distance of 3 mm fuse, breaker switch). In the case where hydraulic connexions are in

insulated material, electrical circuits shall be protected by a differential circuit breaker 30 mA

adapted to local standards.

Thermal circuit breaker (refer to drawings section 5 page 4): All our products are

equipped with a thermostat with thermal circuit breaker and manual resetting which cuts

off the power supply to the water heater in case of overheating. If the safety trips:

 switch off the power before taking any further action,

 remove the cover,

 check the electrical connections,

 reset the thermal circuit breaker

If the circuit breaker keeps tripping, replace the thermostat. Never short circuit the safety cut out or

the thermostat. Connect the power supply only via the terminal.
