8. Changing Revolution Direction

Be sure to change the direction of revolution

only in static condition.

Abuse changing operation may cause broken

tool.

Forward

Backward

Forward/Backward lever can be used to select

direction of revolution.

1. Forward (Turning right): Push the forward/

Backward lever to the extreme of left.

2. Backward (Turning left): Push the forward/

Backward lever to the extreme of right.

9. Adjusting RPM

1. RPM Control Using Shift Switch

The switch features revolution speed control

which can control from zero to Max. speed by

pulling. Pulling more increases revolution speed.

10. Soft Start Feature

Soft Start features decreasing torque transmitted

to the operator and unit when starting the tool with

bit on existing position of hole. It also features

gradual speeding up after the tool is started to

prevent the bit off its working position.

11. Safety Clutch

Safety Clutch feature is activated when a

specied torque level is reached. When Safety

Clutch feature is activated, revolution of bit stops

and motor released.

12. Operating Mode

RH26/36CVR has three operating modes.

1. To drill into stone and concrete and the like,

position the change lever in “Hammer Drilling”

mode as illustrated in the rst diagram. In

“Hammer Drilling” mode, the tool makes drilling

and blowing at the simultaneously. Use drill bit for

“Hammer Drilling” mode.

2. For chiseling and breaking operation, position

the change lever in “Hammer” mode as illustrated

in the second diagram. In “Hammerring” mode,

the tool makes only blowing operation without

revolution of bit. Use ball point or chisel for

operation in “Hammerring” mode.
