6
speed, press the "HIGH/LOW" button. The first press on
this button is for high speed and the second press for
low speed and then each press on this button repeats
the high/low speed cycle alternatively.
Battery remaining capacity indicator (only for
models with Battery BL3622A)
Battery BL3622A is equipped with the battery remaining
capacity indicator.
1
2
011715
Press the CHECK button to indicate the battery
remaining capacity. The indicator lamps will then light for
approx. three seconds.
Indicator lamps
Lighted Off Blinking
EF
Remaining capacity
70% to 100%
45% to 70%
20% to 45%
0% to 20%
Charge the battery.
The battery may have
malfunctioned.
011713
•
When only the lowermost indicator lamp (next to
the "E") blinks, or when none of the indicator lamps
light, the battery capacity has run out, so the tool
does not operate. In these cases, charge the
battery or replace the empty battery with a fully
charged one.
• When two or more indicator lamps do not light
even after charging is complete, the battery has
reached the end of its service life.
• When the upper two and lower two indicator lamps
light alternately, the battery may have
malfunctioned. Contact your local Makita
authorized service center.
NOTE:
• The indicated capacity may be lower than the
actual level during use or immediately after using
the tool.
• Depending on the conditions of use and the
ambient temperature, the indication may differ
slightly from the actual capacity.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing the long nozzle
Fig.3
To install the long nozzle, push in onto the blower outlet
of the tool all the way.
Fig.4
To remove the long nozzle, press its both buttons and
with the buttons being pressed pull it out.
Installing the shoulder strap
Fig.5
Pull the hanger out of the tool.
Hook the shoulder strap onto the hanger of the tool.
Before use, adjust the length of strap so that it is easy to
work with it.
OPERATION
Blowing
Fig.6
Hold the blower firmly with a hand and perform the
blowing operation by moving it around slowly
When blowing around a building, a big stone or a vehicle,
direct the nozzle away from them.
When performing an operation in corner, start from the
corner and then move to wide area.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before attempting to
perform inspection or maintenance.
Cleaning
Fig.7
From time to time, wipe off the outside of the tool using a
cloth dampened in soapy water.
CAUTION:
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
Replacing carbon brushes
Fig.8
Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
1. Indicator lamps
2. CHECK button
