ENGLISH en
9
(continuous beeping). The beeping stops after a
maximum of 30 seconds or when the trigger is
released (6).
Causes and remedies:
1. Ba
ttery pack almost flat (the electronics
prevent the battery pack from discharging totally
and avoid irreparable damage).
If the battery pack is almost flat, it must be
rec
harged.
2. Long continuous overloading of the machine will
a
ctivate the temperature cut-out.
Leave the machine or batt
ery pack to cool.
Note: The machine will cool more quickly if you
operate it at idling speed.
3. If the curr
ent is too high (for example, if the
machine seizes continuously for long periods),
the machine switches off.
Switch off the machine a
t the trigger (6). Then
continue working as normal. Try to prevent the
machine from seizing.
6.2 Battery pack
Charge the battery pack before use.
If performance diminishes,
recharge the battery
pack.
The ideal storage temperature is
between 10°C and
40°C.
Removing the battery pack
Press the battery pack release (7) button and
remove the battery pack (8).
To fit
Slide in the battery back (8) until it engages .
6.3 Setting the direction of rotation,
engagin
g the transporting safety device
(switch-on lock)
Do not activate rotation selector switch (5)
unless the motor has completely stopped!
Actuate the rotation selecto
r switch (direction of
rotation setting, transporting safety device) (5).
See page 2.
R =
Clockwise setting
L = Counter-clockwise setting
0 =
Middle position: transportation safety device
(Switch-on lock) set
6.4 Selecting gear stage
12
1st gear (low speed,
particularly high torque, preferable for
screwing)
12
2nd gear (high speed, preferable for drilling)
6.5 Setting torque control,
drilling
Turn selector barrel (torque, drilling) (3).
1...6 = Torque setting (with torque
control) -
intermediate positions are also possible.
= Drilling stage setting (max. torque,
without torque control)
To avoid motor overloading, do not lock
the spindle.
6.6 Switching power tool on/off, setting
speed
To start the machine, press the trigger (6). The
speed can be changed by pressing in the trigger.
7. Tips and Tricks
If you are working with long screw bits or bit holders,
we recommend the use of the bit clamping bush (1)
provided or the bit clamping brush 6.31281
avail
able as an accessory (see accessories
Chapter).
Drilling
Preferably in 2nd gear (high speed).
Screws
Preferably in 1st gear (low speed) and with torque
co
ntrol.
Screws in areas that are hard to access
The angle screwdriver attachment (see
Acces
sories chapter) greatly facilitates work on
areas that are difficult to access.
Thread tapping
Lubricate the dies.
Select 1st gear (low speed).
Adjust torque control.
8. Accessories
Use only genuine Metabo accessories.
If you need any accessories
, check with your
dealer.
For dealers to select the correct accessory, they
n
eed to know the exact model designation of your
power tool.
See page 4.
A Quick-
clamping chuck.
Fitting: unscrew protective cap (1). Screw the
quick-clamping chuck onto the spindle thread.
The quick-clamping chuck can be tightened
(and released again) with an open-jawed
spanner.
B Angle screwdriver attachment.
CBattery pack
DBattery charger
E Bit clamping bush
FBit box
For a complete range o
f accessories, see
www.metabo.com or the main catalogue.
9. Repairs
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical
tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
