MEASUREMENT FOUNDATION

GroundDrill-14

INSTRUMENTS

THE LEVEL OF OIL IN THE ENGINE

Caution: Oil is a major factor affecting performance and service life. Use detergent

oil. It’s not recommended to use vegetable-based uid. Check the engine oil level

with the engine stopped and in a level position.

Note: SAE 10W-30 is recommended for general use. Use oil SAE Synthetic 5W-

30 when the average temperature in your area is within the recom mended range.

Check the engine with the engine stopped and in a level position.

1.Remove the oil ller cap/dipstick and wipe it clean.

2. Insert the oil ller cap/dipstick into the oil ller neck as shown, but do not screw

it in, then remove it to check the oil level.

3. Add the oil. If the oil level is near or below the lower limit mark on the dipstick.

Note: The Lubricating oil alarm system is used to prevent engine damage due to the

lack of lubricating oil in the crankcase. When the lubricating level of crankcase is

lower than the safety line, the alarm system will shut down the engine automatical-

ly (The engine switch is still in the ON position). If engine can’t start after stopping,

before check other problems, rst check the machine oil level.

THE LEVEL OF OIL IN THE GEAR CASE (for the model GD-14)

Check the level of the oil before running the engine. Check it via monitoring win-

dow. If the level is lower that required, remove the cap of the gear case ller neck

and add oil up to the red dot in the window (as shown in the picture). API GL-4/5

(Volume ~0.7 l. ) is recommended for general use.
