5
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing programme of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE079-1
The tool is intended for impact drilling in brick, concrete
and stone. It is also suitable for screw driving and drilling
without impact in wood, metal, ceramic and plastic.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS HAMMER DRIVER
DRILL SAFETY WARNINGS
GEB056-4
1. Wear ear protectors with impact drilling. Exposure
to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
4. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
5. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
6. Hold the tool firmly.
7. Keep hands away from rotating parts.
8. Do not leave the tool running. Operate the tool
only when hand-held.
9. Do not touch the bit or the workpiece immediately
after operation; they may be extremely hot and
could burn your skin.
1. Red indicator
2. Button
3. Battery cartridge
4. Star marking
5. Switch trigger
6. Lamp
7. Reversing switch lever
8. Speed change lever
9. Action mode changing ring
10. Arrow
11. Adjusting ring
12. Graduation
13. LED indicator
14. Groove
15. Protrusion
16. Steel band
17. Grip base
18. Side grip
19. Sleeve
20. Bit holder
21. Bit
22. Depth rod
23. Clamp screw
24. Hook
25. Screw
26. Blow-out bulb
27. Limit mark
28. Rear cover
29. Screws
30. Arm
31. Spring
32. Recessed part
33. Carbon brush cap
34. Hole
Model BHP448 BHP458
Capacities
Drilling into concrete 14 mm 16 mm
Drilling into steel 13 mm 13 mm
Drilling into wood 65 mm 76 mm
Fastening wood screw 8 mm x 75 mm 10 mm x 90 mm
Fasteing machine screw 6 mm
No load speed
High (2) 0 - 1,800 min
-1
0 - 2,000 min
-1
Low (1) 0 - 350 min
-1
0 - 400 min
-1
Blows per minute
High (2) 0 - 27,000 min
-1
0 - 30,000 min
-1
Low (1) 0 - 5,200 min
-1
0 - 6,000 min
-1
Overall length 225 mm
Net weight 2.2 kg 2.3 kg
Rated voltage D.C. 14.4 V D.C. 18 V
