7. Press the Auto-Drift key to automatically stop the laser beams while the unit is self-leveling. The laser

beams will automatically restart when the unit is leveled.

8. You can use the remote control to control the instrument (see Using the Remote Control). This option is

very useful for trench work or when laying concrete.

9. To turn the instrument off, press the Power key.

Vertical Plane (Automatic Mode)

The instrument can be set up to create a vertical laser line to check the vertical alignment of a wall or fence

pole.

1. Position the instrument on its side on the ground, on any stable surface or on a standard 5/8” tripod (not

included). Set up the instrument approximately level by adjusting the legs or the tripod; the instrument can

compensate for a variance of up to ±5° from the vertical plane.

2. Press the Power key. The Power Indicator will light up. If the instrument is set up outside the ±5° limit the

Manual Indicator will blink, the laser beams with not be projected and rotation will not begin. Please turn off

the instrument and set up again.

3. Verify that the instrument is in automatic mode – the Manual Indicator must be unlit.

4. The instrument is ready for work when the Power Indicator is lit, the Manual Indicator has stopped blink-

ing, and the laser beams are projected. The instrument is now level and the laser head will rotate clockwise

at 600 rpm.

5. To make the beam more visible, change the rotating speed using the speed key, or use the Laser Detector

to detect the laser beam (see Laser Detector).
