MEASUREMENT FOUNDATION

ROTARY 500 HV Servo

7. You can use the remote control to control the instrument (see Using the Remote Control).

8. To return to Automatic mode, press the Auto/Manual key. The Manual Indicator will turn off.

9. To turn the instrument off, press the Power key.

Plumb Down

The Plumb Down feature enables you to center the instrument onto a selected point. It is much easier to use

this feature if you set up the instrument on a tripod with a hollow connecting bolt.

1. Set up the instrument on a tripod.

2. Move the tripod and instrument so that they are approximately above the selected point.

3. Level the instrument as in Horizontal Setup.

4. Press the Power key to turn the instrument.

5. Move the Plumb Down beam onto the selected point on the ground by raising and lowering the tripod

legs.

6. Level the instrument again, and adjust the Plumb Down beam with the tripod legs as in step 5.

7. Repeat step 6 until the Plumb Down beam is sufciently accurate for your purposes.

8. If you wish to transfer a point to the ceiling, use the Plumb Up beam once the instrument is accurately

centered.

Changing Rotation Speed

The laser beam is more visible when the rotating speed is slower. Change the speed of the rotating laser

head by pressing the Speed key. The default option is 600 rpm. Pressing the key moves a step forward in

the speed cycle (600-0-60-120-300-600-rpm).
