23687-001_v01
Technical data
Technical parameters are given on the product’s data plate.
Allowed time of continuous work
of the meat mincer 10 minutes.
Required break before following use
of the meat mincer 30 minutes.
Noise of the meat mincer (L
WA
) 80 dB/A.
The appliance features double electrical insulation (Class II)
and does not require grounding.
ZELMER meat mincers meet the requirements of the
following applicable standards.
The meat mincer complies with the requirements of the
following directives:
Low voltage device (LVD) – 2006/95/EC. –
Electro-magnetic compatibility (EMC) – 2004/108/EC. –
The product has been marked with the CE mark on the data
plate.
Description
The meat mincer consists of:
1
Drive unit – each drive of the machine is adjusted to the
assembly of each of the mincing set and the shredder
produced by ZELMER. There are some ventilation inlets
in rear casing of the 687 drives.
1a
Switch
1b
Lock button
Mincing set, which consists of:
2
Mincing chamber
3
Feed screw with assembled coupling
4
Double-side cutter
5
Screen with 4mm holes
6
ring collar
7
Food tray
8
Pusher
Equipment, which includes:
9
Screen with 8 mm holes
10
Sausage stuffer
11
Separator
A
TYPES OF ZELMER MEAT MINCERS
Below, you can see an assortment of equipment anticipated for the meat mincers, which the user manual refers to.
Typ Cutter knife
Screen
Sausage stuffer
Pasta and pastry
set
Shredder
2,7 4 8
687.5
● ○ ● ● ● ○ ○
687.54
● ○ ● ● ● ○ ●
● – basic accessories, ○ – additional equipment, which can be bought in shops, household appliances stores,
–
– unavailable accessories
The mincer is equipped with one mincing unit.
Mechanical safety device for the motor
1
Scroll
2
Clutch
3
Screw M5x20
The meat mincer is equipped with mechanical protection,
which secures the motor against any damage – teeth of
the coupling break, when the meat mincer is overloaded
(f. ex. when bones have entered into the mincing chamber).
The broken coupling should be replaced with a new one:
unscrew the coupling from the feed screw
●
(3),
remove the broken coupling
●
(2),
put on the new coupling
●
(2) and screw it (3).
Preparing the meat mincer to work
and the actuation of the appliance
1
Place the drive (1) unit close to the power network
socket, on a rm surface so as not to cover the ventilation
holes within the casing.
Before the rst use of the meat mincer, wash the
●
equipment elements.
Assemble the appropriate equipment and join it with the
●
drive unit.
2
Put the power cord into the supply network socket.
3
Turn the meat mincer on with the main switch (1a).
Operating the mincing set
Insert the following parts into the mincer body (2):
1
Insert the scroll (3) with the coupling facing inside.
2
Fit the knife (4) onto the pin of the scroll (3).
3
Place the screen (e.g. 5) over the knife so that the
protrusion in the mincer body will t into the groove in the
circumference of the screen.
4
Tightly t all the elements of the mincer unit.
5
Fit the assembled mincer unit onto the drive unit (1) and
turn it until you hear a click of the lock. It means that the body
has been properly installed.
6
Place the tray (7) on the mincer body (2).
B
C
D
