SP 500
Version 2.0 © TROTEC Produktions- u. Vertriebs GmbH
12 / 51
Technical changes reserved Freilingerstraße 99, A-4614 Marchtrenk
www.troteclaser.com
TroCAM Basic / Advanced CAD / CAM software for perfect cutting results; inclusively nesting-function, lead-
in/lead-out, tool paths
Extraction System lead /follow-
up time
Lead- and follow-up time fully adjustable
• Control System
Software JobControl Expert
Laser power Adjustable 0 – 100%
Interface hardware USB, RS-232 (RS-232 mandatory for TroCAM and CCD-camera)
Interface software ASCII, HPGL, AD-Logic System
• Laser
features and power
levels
Laser features and power lev-
els
Sealed-off CO
2
laser
With 40 – 200 watts, air – or water cooled (depending on model)
Wavelength 10,6µm
• Dimensions
Width x depth x height 1920 x 1240 x x1140 (780 without base frame) mm or
75.5 x 48.8 x 45.0 (30.7 without base frame) inches
Weight 520 - 580 kgs / 1100 - 1300 lbs (depending on laser power)
Ambient conditions Mandatory ambient temperature +15° to +25° C or 59° to 77° F
Humidity 40% to max.. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
• Laser Safety
Laser class CDRH laser safety; CE tested
Laser class 2 (Laser class 4 with pass-through)
Interlock Duplicate interlock safety system
Loading lid Front side loading lid
• Exhaust (Minimum requirements)
Volume Min. 640 m³/h at 8500 pa
• Electrical Equipment
Power consumption Up to 5,6 kW
Up to incl. 120 W Laser power 1x230V (L+N+PE) 50/60Hz
200 W Laser power 3x230V (3xL+N+PE) 50/60Hz
