SP 500
Version 2.0 © TROTEC Produktions- u. Vertriebs GmbH
23 / 51
Technical changes reserved Freilingerstraße 99, A-4614 Marchtrenk
www.troteclaser.com
Signage
The warning and information labels are attached in such positions of the device that could
represent a source of danger during set-up and operation. Therefore, follow the
information on the labels. If labels are lost or damaged, they must be replaced
immediately.
VISIBLE LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
EN 60825-1:2003
CAUTION
INVISIBLE CLASS 4 LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED:
AVOID EYE OR SKIN EXPOSURE TO DI-
RECT OR SCATTERED RADIATION
LIFTING POINTS
LASERDIODE
MAX. POWER <0.99mW cw
WAVELENGTH 655nm
<- DO NOT LIFT HERE ->
NEVER OPERATE THE LASER SYSTEM
WITHOUT CONSTANT SUPERVISION:
EXPOSURE TO THE LASER BEAM MAY
CAUSE IGNITION OF COMBUSTIBLE MATE-
RIALS WHICH CAN CAUSE SEVERE DAM-
AGE TO THE EQUIPMENT
CAUTION
VISIBLE LASER RADIATION
WHEN OPEN DO NOT STARE INTO BEAM
BEFORE OPEN
UNPLUG THE MACHINE FIRST
INPUT POWER
380-400 VAC 50Hz
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED:
AVOID EYE OR SKIN EXPOSURE TO DI-
RECT OR SCATTERED RADIATION
Warning of
laser radiation
Warning of
electrical power
Warning of
hand injury
Warning of
fire
Serial number
