SpeedMarker 300
8037 | V 2.1_EN (01/2016)
25/ 51
Options / Accessories
Optional lenses and galvo scanners
F-100, F-16, F-254
High-speed scan heads with lenses
Focus finder
Second pilot laser for precise and user friendly adjustment of working
distance
Software
DirectMark printer driver: Laser marking as easy as printing. Independ-
ent from software
Extended I/O interface
Additional in- and outputs, 24 VDC
Pass-through
Optional pass-through for marking of larger parts. Machine will become
laser class 4; not retrofitable
Additional optional accessories
Software controlled Z-axis
Mini rack for computer and laser unit
Rotary unit with different chucks
Foot switch for efficient and user friendly control of the system
Exhaust systems
Dimensions / Installation / Laser Safety
Dimensions (W x H x D)
Marking head: 120 x 138 x 528 mm³
Laser rack unit: 483 x 140 x 686 mm³
(equals 3RU, 19" compatible)
PC: 483 x 140 x 410 mm³
(equals 3RU, 19" compatible)
Footprint (W x D)
(with software controlled Z-axis)
572 x 851 mm²
(445 x 851 mm²)
Height (with open door)
653 mm (938 mm)
Weight
App. 48 kg (without PC, laser rack and marking head)
PC: app. 11,5 kg, laser rack: app. 17 kg
Ambient conditions
Operating temperature range +5 to +35° C.
Relative humidity max. 90 %; Non-condensing
Electrical requirements
115 - 230 VAC, 50/60 Hz, 1/N/PE
Power consumption
< 600 W (incl. PC)
System protection
Marking head: sealed against spray water (IP 54)
Laser rack unit: dust protected (IP20)
Laser class
CDRH laser safety; laser class 2; CE tested
