English Operating Manual – Snowthrower

• With the coupling levers (1 and 2)

released, choose a forwards gear

with shift lever (6).

• Press coupling lever for worm

drive (1) and hold it down; worm

and throw turbine are driven.

• Press coupling lever for the drive

system (2) and hold it down; the

machine moves forwards and

clears the snow. As long as this

lever is pressed, the coupling lever

for the worm drive (1) is locked in

position and you can let go of it.

• If you want to change gear, first

release the coupling lever for the

drive system (2) and then change

gear with the shift lever (6).

Working on slopes

Risk of injury from machine

tipping over

Work slowly and carefully, especially

when you change direction.

Guide the machine up or down the

slope, not crosswise to it.

Watch out for obstacles, do not work

near inclines.

Do not use the machine on slopes

with a gradient greater than 20 %.

Tips on clearing snow

• Clear snow immediately after it has

stopped snowing; later on, the

underneath layer will ice up and

will make clearing the snow more

difficult.

• If at all possible, clear snow in the

direction of the wind.

• Clear the snow in such a way that

the tracks you have cleared

overlap slightly.

Set the direction and

distance of throw

Figure 8

Risk of injury

Do not set the flap (2) of the throw-

out chute (3) in the direction of

people, animals, windows, cars and

doors.

Set the direction of throw

• Put the throw-out chute (3) in the

desired direction by rotating the

handle (Figure 1, item 7)

Set the throw distance

The steeper the angle of the flap (2)

is set, the higher and further the

snow will be ejected.

• For machines with lever (Figure 1,

item 5): press lever forwards to set

the flap (2) higher and back for

lower.

• For machines without lever: loosen

knob (1) and set flap (2) higher or

lower as required.

Start the engine

Figure 2

Danger

If you start the engine in an enclosed

space, move the machine

immediately afterwards into the open

air. Never leave the engine running

in an enclosed space.

Before starting the engine, release

coupling levers (Figure 1, items 1

and 2)/coupling bar (Figure 1,

item 1).

• Check contents of fuel tank and oil

level, as required fill up with oil and

fuel (see “Engine instructions”).

Start with pull starter

• Set shut-off valve (10), if this is

present, to “ON”.

• Put spark-plug connector (8) onto

the spark plug.

• Set throttle lever (7) to “ ”.

• For a cold start, set choke (2) to

“ ”/“ON”.

• Insert ignition key (1) in the ignition

lock.

• Press primer knob (3) once. In cold

weather press it twice or three

times.

• Pull the pull starter (4) slowly until

some resistance is felt, then

quickly and vigorously. Do not let

the pull starter recoil quickly but

lead it back slowly.

• Set choke (2) back progressively

to “OFF”.

Start with electric starter

(optional)

To start the engine, the electric

starter must be connected to the

mains power supply.

Risk of electric shock

Make sure that the mains supply

network is protected with a fault

current circuit-breaker. If required,

have an appropriate circuit-breaker

fitted, but only by a trained

electrician.

For connecting the electric starter to

the mains, use only extension cables

(not supplied with the machine)

which are approved for use in the

open air and which are protected by

an earth wire, e.g. up to a maximum

length of 50 m:

– H07RN-F 3x1.5 mm² up to –25 °C

– H07BQ-F 3x1.5 mm² up to –40 °C.

Caution

If the electric starter is not connected

properly, damage could occur to the

machine or in its vicinity.

Make sure that the mains supply

network

– is operating in conformity with the

specifications on the starter

identification plate (Figure 2,

item 9) at 220–230 V and 50 Hz

– is protected by an appropriate fuse

system.

• Put spark-plug connector (8) onto

the spark plug.

• Set throttle lever (7) to “ ”.

• Insert ignition key (1) in the ignition

lock, but do not turn it.

• Connect extension cable first with

the plug (5) and then with a mains

socket.

• Set choke (2) to “OFF”.

• Press starter button (6) long

enough (max. 5 sec.) for the

engine to start. For a cold start, set

choke (2) while the starter button is

being pressed to “ ”. Wait at least

10 sec. before attempting to start

the engine again.

• As required, set the choke (2)

progressively back to “OFF”.

• Separate the extension cable first

from the mains and then from the

electric starter.
