Octave V 70 SE [6/33] Safety instructions
![Octave V 70 SE [6/33] Safety instructions](/views2/1406119/page6/bg6.png)
9
2. SAFETY INSTRUCTIONS
2.2. Placement
1. Location
OCTAVE equipment is designed strictly for use in a dry domestic environment. Do not use it in the
open air or in damp environments!
Never place plants or liquid-filled containers on your OCTAVE equipment. Take care to avoid
dropping objects or spilling liquids into the case. Should this happen, remove the mains plug
immediately and have your amplifier checked by a qualified service technician.
Condensation may form if the amplifier is taken from a cold environment into a warm one. If you do
this, wait until the amplifier has reached room temperature and is dry before switching it on.
Avoid installing the unit close to sources of heat such as radiators or anywhere that may be in
direct sunlight.
Do not operate the unit near flammable materials, gases or vapors. Avoid areas where there may
be heavy accumulations of dust or where the unit may be subject to mechanical vibration.
Place your OCTAVE amplifier on a stable, level surface.
2. Grille
Never operate the amplifier without the protective grille in place.
3. Ventilation
Make sure that your amplifier has an adequate flow of air around it. If you intend to install your
equipment into a cupboard or on a wall shelf unit, ensure that there is at least a ten centimeter (4
inch) gap between the ventilation slots and the walls all around the amplifier. The rear panel of
cupboards should have ventilation holes to prevent heat build up. Do not rest the equipment on a
soft surface such as carpet or foam sheeting.
2.3. Warranty
OCTAVE can only guarantee the safety, reliability and performance of this unit if modifications and
repairs are carried out by specialized personnel and when the amplifier is operated in accordance
with the instructions contained in this manual.
