Airwell VH2N 05 [5/16] Air flow data continued
![Airwell VH2N 05 [5/16] Air flow data continued](/views2/1408150/page5/bg5.png)
Page 5
VH2N 21 - Air Flow (m
3
/h)
Air Flow Data (continued)
VH2N 24 - Air Flow (m
3
/h)
VH2N 27 - Air Flow (m
3
/h)
Speeds Filter
External static pressure (Pa)
0 25 50 75 100 125 150 180 200
V1
Without 1200 1091 971 840 702 - - - -
G2 1193 1083 963 834 697 - - - -
G3 1186 1074 954 827 693 - - - -
V2
Without 1886 1795 1703 1606 1500 1384 1258 - -
G2 1864 1775 1684 1588 1483 1368 1243 - -
G3 1843 1756 1666 1571 1466 1352 1230 - -
V3
Without 2571 2445 2325 2204 2075 1936 1782 1575 -
G2 2514 2397 2282 2163 2036 1898 1747 1545 -
G3 2464 2352 2240 2124 1999 1863 1714 1516 -
V4
Without 3500 3323 3147 2962 2768 2562 2348 2076 1882
G2 3371 3200 3022 2838 2648 2451 2243 1976 1784
G3 3257 3084 2912 2738 2558 2371 2172 1916 1732
Speeds Filter
External static pressure (Pa)
0 25 50 75 100 150 200 210 220
V1
Without 2970 2898 2814 2724 2629 2425 2171 - -
G2 2930 2864 2784 2695 2601 2397 2141 - -
G3 2865 2783 2706 2628 2546 2350 2095 - -
V2
Without 3505 3422 3334 3236 3129 2888 2607 2541 -
G2 3460 3379 3289 3189 3081 2842 2560 2493 -
G3 3410 3337 3235 3124 3013 2780 2472 2396 -
V3
Without 4420 4279 4143 3991 3821 3454 3038 2942 2839
G2 4300 4175 4036 3880 3712 3357 2946 2850 2748
G3 4225 4076 3940 3784 3614 3258 2821 2717 2610
Speeds Filter
External static pressure (Pa)
0 25 50 75 100 150 200 210 220
V1
Without 3000 2918 2832 2741 2646 2434 2163 - -
G2 2960 2880 2798 2714 2624 2418 2146 - -
G3 2920 2846 2770 2691 2605 2402 2129 - -
V2
Without 3500 3398 3300 3190 3067 2795 2472 2393 -
G2 3450 3348 3245 3134 3013 2737 2398 2316 -
G3 3400 3278 3182 3085 2971 2693 2355 2275 -
V3
Without 4380 4230 4075 3908 3725 3314 2856 2755 2646
G2 4310 4186 3984 3792 3614 3209 2718 2613 2500
G3 4240 4082 3893 3705 3516 3091 2590 2477 2353
