CONTROLS
The standard units are supplied without any controls.
A manual fan speed selector or a remote control thermostat can be supplied as optional item.
If a TRM remote temperature regulation thermostat is supplied, it must only control a single unit. If this is not the
case, you must include a relay box in the circuitry.
OPTIONAL ELECTRIC HEATER
On request, all fan coil units can be factory mounted with an electric heater.
The heating rod type electric heating is inserted directly into a finned exchanger.
The latter may be a single block unit for sizes 10. 80. 90 or with an additional block for sizes 20 to 70.
Do not install the electric heater on existing unit without using the supply air grilles resistant to high temperature.
Factory-fitted electric heating batteries are equipped with an automatic and manual reset temperature limiting safety
device in compliance with IEC 66375.
Size BE1 BE2 BE3 BE4
10 200 400
600 (1)
(200+400)
ND
20 300 600
900 (1)
(300+600)
ND
30 300 600
900 (1)
(300+600)
1200 (1)
(600+600)
40 500 1000
1500 (1)
(500+1000)
2000 (1)
(1000+1000)
50 600 1200
1800 (1)
(600+1200)
2400 (1)
(1200+1200)
60 750 1500
2250 (1)
(750+1500)
3000 (1)
(1500+1500)
70 750 1500
2250 (1)
(750+1500)
3000 (1)
(1500+1500)
80 900 1800
2700 (1)
(900+1800)
3600 (1)
(1800+1800)
90 1000 2000
3000 (1)
(1000+2000)
4000 (1)
(2000+2000)
Electric heater capacities
Electric heaters with heating rods (supplied fitted)
(1) : Available in 2 steps suitable for Aqu@Net control.
NA : Not available.
