DIMENSIONS
NET WEIGHT
SEE APPENDIX
TECHNICAL SPECIFICATIONS
IMPORTANT
These datas are given for guidance only. They must be checked aat commissioning according to prevailing standards.
They depend on the installation and the cables used.
A main fuse must mandatorily be provided on the power supply.
Fuses not supplied
Cables not supplied
Sizes AWC AWN AHC AHN
10 / 11 / 11
20 20 14 20 14
30 23 16 23 16
40 30 23 30 23
50 35 27 35 27
60 39 30 39 30
70 42 34 42 34
80 50 41 50 41
90 56 46 56 46
without Electric heating
Size 10 20 30 40 50 60 70 80 90
Power supply
V 230V-50Hz ALTERNATIF
Fan motor power W 35 41 60 57 63 110 132 190 295
Fuse rating Am A 2
Fuse rating ASE / VDE A 2
Cable section mini mm² 3G1.5
with Electric heating
Size 10 20 30 40 50 60 70 80 90
Power supply
V 230V-50Hz ALTERNATIF
Electric heating capacity BE1 W 200 300 500 600 750 900 1000
Fuse rating Gg A 4
Fuse rating ASE / VDE A 10
Cable section mini mm² 3G1.5
Electric heating capacity BE2 W 400 600 1000 1200 1500 1800 2000
Fuse rating Gg A 4 6 8 10 12
Fuse rating ASE / VDE A 10 16
Cable section mini mm² 3G1.5 3G2.5
Electric heating capacity BE3 W 600 900 1500 1800 2250 2700 3000
Fuse rating Gg A 6 8 10 12 16
Fuse rating ASE / VDE A 10 16
Cable section mini mm² 3G1.5 3G2.5
Electric heating capacity BE4 W 1200 2000 2400 3000 3600 4000
Fuse rating Gg A 8 12 16 20
Fuse rating ASE / VDE A 10 16 25
Cable section mini mm² 3G1.5 3G2.5 3G4
weight in kilograms
