![Airwell Aqu@Fan AHC 5030 [22/44] Appendix annexe anlage allegato anexo](/img/pdf.png)
Airwell Aqu@Fan AHC 5030 [22/44] Appendix annexe anlage allegato anexo
![Airwell AQU@FAN AWC 2030 [22/44] Appendix annexe anlage allegato anexo](/views2/1408355/page22/bg16.png)
APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO
IV
AWN
15
15
70
145
100
130
A
B
2 220
100
108
B
D
C
A
H
G
F
E
D
C
I
J
15 15
20 14
A
132
166
AHN
70
A
143
30
17
B
2
B
D
C
A
G
H
220
J
I
F
E
D
C
A
1515
143
K
70
220
Attention ! Ne pas fixer la gaine sur le rebord du
bac à condensats (démontage du bac compromis)
15
15
17
15
70
A
L
N
M
A : auxiliary coil water inlet
B : auxiliary coil water outlet
C : main coil water inlet
D : main coil water outlet
Caution ! Do not fix duct to edge of condensate
drain pan, in order to allow pan removal.
A B C D E F G H I J
10 370 430 406 390 255 238 54 95 141 182
20 510 430 408 390 256 236 52 95 141 183
30 695 430 408 390 256 236 52 95 141 183
40 880 430 408 390 256 236 52 95 141 183
50 1065 430 408 390 256 236 52 95 141 183
60 1250 430 408 390 256 236 52 95 141 183
70 1065 530 506 492 289 233 41 88 145 172
80 1250 530 500 489 245 234 40 83 143 186
90 1435 530 500 489 245 234 40 83 143 186
A B C D E F G H I J K L M N
10 370 430 406 390 255 238 54 95 141 182 583 122 30 68
20 510 430 408 390 256 236 52 95 141 183 723 122 30 68
30 695 430 408 390 256 236 52 95 141 183 908 122 30 68
40 880 430 408 390 256 236 52 95 141 183 1093 122 30 68
50 1065 430 408 390 256 236 52 95 141 183 1278 122 30 68
60 1250 430 408 390 256 236 52 95 141 183 1463 122 30 68
70 1065 530 506 492 289 233 41 88 145 172 1278 123 32 65
80 1250 530 500 489 245 234 40 83 143 186 1463 123 32 65
90 1435 530 500 489 245 234 40 83 143 186 1648 123 32 65
A : entrée eau batterie auxiliaire
B : sortie eau batterie auxiliaire
C : entrée eau batterie principale
D : sortie eau batterie principale
A : auxiliary coil water inlet
B : auxiliary coil water outlet
C : main coil water inlet
D : main coil water outlet
A : auxiliary coil water inlet
B : auxiliary coil water outlet
C : main coil water inlet
D : main coil water outlet
A : entrée eau batterie auxiliaire
B : sortie eau batterie auxiliaire
C : entrée eau batterie principale
D : sortie eau batterie principale
