![Airwell Aqu@Fan AWN 3030 [43/44] Declaración ce de conformidad](/views2/1408355/page43/bg2b.png)
And that the following paragraphs of the harmonised standards have been applied.
Et que les paragraphes suivants les normes harmonisées ont été appliqués.
Und dass die folgenden Paragraphen der vereinheitlichten Normen Angewandt wurden.
E che sono stati applicati i seguenti paragraphi delle norme armonnizzate.
Y que se han aplicado los siguientes apartados de las normas armonizadas.
AQU@FAN II - Type AWC / AHC / AWN / AHN
Mod: 10-20-30-40-50-60-70-80-90
LOW VOLTAGE DIRECTIVE 2006 / 95 / EC
ELECTROMAGNETIC COMPATIBILITY DIRECTIVE 89 / 336 / EC AMENDED BY 92 / 31 / EC AND 93 / 68 / EC
PRESSURISE EQUIPMENT DIRECTIVE 97 / 23 / EC
SUB-MODULE A CATEGORY I
DIRECTIVE BASSE TENSION 2006 / 95 / C.E.E.
DIRECTIVE COMPATIBILITE ELECTROMAGNETIQUE 89 / 336 / C.E.E. AMENDEE PAR DIRECTIVE 92 / 31 / C.E.E ET 93 / 68 / C.E.E
DIRECTIVE DES EQUIPEMENTS SOUS PRESSION 97 / 23 / C.E.E.
SOUS-MODULE A CATEGORIE I
RICHTLINIE NIERDERSPANNUNG 2006 / 95 / EG
RICHTLINIE ELEKTROMAGNETISHE VERTRÄGLICHKEIT 89 / 336 / EG ABGEÄNDERT DURCH DIE RICHTLINIE 92 / 31 / EG UND 93 / 68 / EG
RICHTLINIE FÜR AUSRÜSTUNGEN UNTER DRUCK 97 / 23 / EG
UNTER MODUL A, KATEGORIE I
DIRETTIVA BASSA TENSIONE 2006 / 95 / CEE
DIRETTIVA COMPATIBILITA ELETTROMAGNATICA 89 / 336 / CEE EMENDATA DALLA DIRETTIVA 92 / 31 / CEE E 93 / 68 / CEE
DIRETTIVA DEGLI IMPIANTI SOTTO PRESSIONE 97 / 23 / CEE
SOTTOMODULO A, CATEGORIA I
DIRECTIVA BAJA TENSION 2006 / 95 / CEE
DIRECTIVA COMPATIBILIDAD ELECTROMAGNETICA 89 / 336 / CEE ENMENDATA POR LA DIRECTIVA 92 / 31 / CEE Y 93 / 68 / CEE
DIRECTIVA DE LOS EQUIPOS A PRESION 97 / 23 / CEE
BAJA MODULO A, CATEGORIA I
Déclaration CE de conformité
Nous déclarons sous notre responsabilité que les produits désignés dans la présente notice sont conformes aux dispositions des directives CEE énoncées
ci- après et aux législations nationales les transposant.
EC Compliance declaration
Under our own responsibility, we declare that the product designated in this manual comply with the provisions of the EEC directives listed hereafter
and with the national legislation into which these directives have been transposed.
EG-Konformitätserklärung
Wir erklarën in eigener Verantwortung, das die in der vorliegenden Beschreibung angegebenen Produkte den Bestimungen der nachstehend erwähn-
ten EG-Richtlinien und den nationalen Gesetzesvorschriffen entsprechen, in denen diese Richtinien umgesetz sind.
Dichiarazione CE di conformità
Dichiariamo, assurmendone la responsasabilità, che i prodotti descritti nel presente manuale sono conformi alle disposizioni delle direttive CEE di cui
sott e alle lagislazionni nazionali che li recepiscono
Declaramos, bajo nuestra responsabilidad, que los productos designados en este manual son conformes a las disposiciones de las directivas CEE enu-
nuciadas a continuacion, asi como a las legislaciones nacionales que las contemplan.
Declaración CE de conformidad
EN 60 335-1 EN 60 335-2-40
EN 55 014-1 EN55 014-2
A Tillières Sur Avre
27570 - FRANCE
Le: 27/04/2007
Franck Bailly
Quality Manager
ACE Industrie
