![Airedale Ultima FreeCool UFC 225 [10/46] Ultima freecool chillers](/views2/1409517/page10/bga.png)
ULTIMA FREECOOL Chillers
Chillers
10
Installation & Maintenance Manual : 903-125 IM E 05/04/A
Installation Data
DIMENSIONS (CONT.)
DSQ Models A BCDE F G
UFC200DSQ-8 mm 4945 760 1850 1850 - - 485
UFC225DSQ-8 mm 4945 760 1850 1850 - - 485
UFC250DSQ-8 mm 4945 760 1850 1850 - - 485
UFC275DSQ-10 mm 5795 760 1550 1450 1550 - 485
UFC300DSQ-10 mm 5795 760 1550 1450 1550 - 485
UFC350DSQ-14 mm 7670 610 1100 1725 1920 1830 485
UFC400DSQ-14 mm 7670 610 1100 1725 1920 1830 485
UFC450DSQ-16 mm 8520 610 1100 2375 2120 1830 485
UFC500DSQ-16 mm 8520 610 1100 2375 2120 1830 485
UFC575DSQ-18 mm 9370 585 1100 2400 2400 2375 460
UFC650DSQ-18 mm 9370 585 1100 2400 2400 2375 460
UFC700DSQ-20 mm 10220 585 1100 2400 2800 2825 460
UFC750DSQ-20 mm 10220 585 1100 2400 2800 2825 460
CAUTION
8 Lifting points on 20 fan models.
Mounting Holes x 20mm Ø Quantity
8 Fan Unit 6
10 Fan Unit 8
12 Fan Unit 8
14 Fan Unit 10
16 Fan Unit 10
18 Fan Unit 10
20 Fan Unit 10
POINT LOADING &
CENTRE OF GRAVITY
Please contact Airedale.
