ULTIMA FREECOOL Chillers
Chillers
28
Installation & Maintenance Manual : 903-125 IM E 05/04/A
Commissioning Data
GENERAL DATA
Operating Limits
Unit with Electronic Fan Speed HP Control (-20°C)
Minimum Ambient Air DB °C -20°C
Maximum Ambient Air DB °C Refer to Technical Manual - Performance Data
Minimum Leaving Water Temperature °C +5°C
Maximum Return Water Temperature °C +20°C
For conditions outside those quoted, please refer to Airedale.
MECHANICAL DATA
Oil & Refrigerant Charges
STANDARD D UFC200D-8 UFC225D-8 UFC250D-8 UFC275D-8 UFC300D-8
Compressor Screw - Semi Hermetic
Quantity 2 2 2 2 2
Oil Charge Volume (Total) l 5.5 + 5.5 5.5 + 5.5 5.5 + 5.5 7.5 + 5.5 7.5 + 7.5
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 40 + 40 45 + 40 45 + 45 50 + 45 50 + 50
QUIET DQ UFC200DQ-8 UFC225DQ-8 UFC250DQ-8 UFC275DQ-8 UFC300DQ-8
Refrigerant Charge/Circuit kg 40 + 40 45 + 40 45 + 45 50 + 45 50 + 50
SUPER QUIET DSQ UFC200DSQ-8 UFC225DSQ-8 UFC250DSQ-8 UFC275DSQ-10 UFC300DSQ-10
Refrigerant Charge/Circuit kg 40 + 40 45 + 40 45 + 45 60 + 55 60 + 60
STANDARD D UFC350D-10 UFC400D-10 UFC450D-12 UFC500D-12 UFC575D-14
Compressor Screw - Semi Hermetic
Quantity 2 2 2 2 2
Oil Charge Volume (Total) l 7.5 + 7.5 7.5 + 7.5 10 + 7.5 10 + 10 10 + 10
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 75 + 70 75 + 75 90 + 85 90 + 90 105 + 100
QUIET DQ UFC350DQ-12 UFC400DQ-12 UFC450DQ-14 UFC500DQ-14 UFC575DQ-16
Refrigerant Charge/Circuit kg 85 + 80 85 + 85 100 + 95 100 + 100 115 + 110
SUPER QUIET DSQ UFC350DSQ-14 UFC400DSQ-14 UFC450DSQ-16 UFC500DSQ-16 UFC575DSQ-18
Refrigerant Charge/Circuit kg 95 + 90 95 + 95 110 + 105 110 + 110 125 + 120
STANDARD D UFC650D-14 UFC700D-18 UFC750D-18
Compressor
Quantity
Oil Charge Volume (Total) l 10 + 10 14 + 10 14 + 14
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 105 + 105 130 + 125 130 + 130
QUIET DQ UFC650DQ-16 UFC700DQ-18 UFC750DQ-18
Refrigerant Charge/Circuit kg 115 + 115 130 + 125 130 + 130
SUPER QUIET DSQ UFC650DSQ-18 UFC700DSQ-20 UFC750DSQ-20
Refrigerant Charge/Circuit kg 125 + 125 140 + 135 140 + 140
