Chillers ULTIMA FREECOOL
Chillers
Installation & Maintenance Manual : 903-125 IM E 05/04/A
25
Controls
OPERATION (CONT..)
Standard Operating
Page cont./
The following Menus can be accessed from the Operating Page, it is recommended that
the display is always returned to the Operating Page by using the
Esc
key
To guard against unauthorised adjustments, a password is required to gain access to
certain menus as defined below.
FACTORY SET PASSWORD PIN NUMBER: 4648 (or Customer chosen number).
Password Protection
When a password is requested use the keys to enter the number and to
access the page.
Menu Description Password
Menus
(Listed in Sequence)
Service
Allows selection of setpoint limits, enables unit on/off
from display, remote on/off and remote pump on/off.
Default 4648
Setpoint
Allows setpoint adjustment, includes supply
temperature setpoint and unit temperature
differential.
Default 4648
Status
Displays current status on digital and analogue inputs
and outputs.
Open Access
Maintenance
Displays hours run for compressors and pumps (if
fitted). Also includes Electronic Expansion Valves (if
fitted).
Default 4648
Clock
Allows adjustment of real time clock, time zones Default 4648
Alarm Log
Display last 100 alarms in chronological order.
Open Access
Manufacturer
Factory use only.
Airedale Only
SETTING UP
Unit ON/OFF
By pressing the
Esc
and simultaneously for approximately 5 seconds, the unit
operation will stop or start.
Real Time Clock
The units leave the factory set, however follow the Navigation instructions if necessary.
Time Zones
The programme provides 3 On/Off periods per day, 7 days per week. The unit is factory
set for continuous operation.
Technical Support
For further details, please contact Airedale.
