STEP 5 – The ﬁnishing touches – PICTURE 5

Use the clipper without an attachment comb for close trimming around the base and sides

of the neck. Use the ear comb guides to get a clean line around each ear. For the required

ear comb guide, angle the clipper and lightly stroke around each ear to the back of the

neck.

To produce a clean straight line at the sideburns, reverse the hair clipper. Place the

reversed clipper at right angles to the head, tips of the blades lightly touching the skin and

then work downwards.

TAPER LEVER (DIAGRAM 6)

This product has a taper lever located at the left side of the clipper near the blades. Adjust

the lever to change the closeness of the cut gradually and also to improve the effectiveness of

the comb attachments. The taper lever also extends the life of the blades because a different

cutting edge is used in each setting.

CARE FOR YOUR HAIRCLIPPER

Your clipper is ﬁtted with high quality titanium blades that are permanently lubricated. To

ensure long lasting performance of your clipper, clean the blades and unit regularly. Always

keep the protective cap on the clipper blade.

AFTER EACH USE

Ensure the clipper is switched off and disconnected from the mains.

Brush the accumulated hair from the blades. Do not submerge the clipper in water.

To clean the unit, wipe with a damp cloth and dry immediately.

To reattach, line up the locating tab and then push blade set back onto main unit.

Note: Ensure that the clipper is turned off when cleaning.

EVERY SIX MONTHS

At regular intervals the Blade Set should be removed and cleaned.

Remove the 2 screws retaining the ﬁxed blade with a screwdriver. Do not remove blade set.

Brush out hairs from between the blades with soft cleaning brush. Do not remove the

lubricating grease from the blades. Do not remove the small moving blade.

Before fully tightening the 2 screws, adjust the taper lever to the lower position and align

the blades so that their cutting edges are parallel to one another. Tighten the 2 screws.

Note that if the blades are not correctly aligned then cutting efﬁciency will be impaired.

CAUTION:

Do not use liquid cleaners on the blades or harsh or corrosive chemicals on the blade

casing. Always use a soft brush to remove the accumulated hairs.

Always store this appliance in a moisture-free area.

Do not wrap the cord around the appliance.
