7
English
Inserting batteries into the Remote
Control
1
Open the battery cover by pressing in the tab, then lift off
the cover.
2
Insert batteries with the correct polarity as indicated by
the +
and -
symbols inside the battery compartment.
3
Close the cover.
CAUTION!
– Remove batteries if they are exhausted or not to
be used for a long time.
– Do not use old and new or different types of
batteries in combination.
– Batteries contain chemical substances, so they
should be disposed off properly and kept away
from children.
Using the Remote Control
●
Direct the remote control at the remote sensor of the
DVD player.
●
Do not drop or give the remote control a shock.
●
Do not leave the remote control in extremely hot or
humid places.
●
Do not spill water or put anything wet on the remote
control.
NTSC/PAL Conversion
This player is equipped with a NTSC/PAL conversion
feature to convert the video output of the disc to match
your TV system. The conversions supported are as
below. To activate the conversion, refer to “TV TYPE”:
Notes:
– “MULTI” can only be selected when using a TV that has
both the NTSC and PAL systems.
– Slight picture distortions may occur due to this conversion.
This is normal. Thus, the “MULTI” is most suitable for the
best picture quality.
Turning on the power
1
Connect the AC power cord to the power outlet.
2
Turn on the TV and your AV receiver.
3
Select the appropriate input source at the AV receiver
that was used to connect to this unit. Refer to the
equipment owner’s manual for detail.
4
Turn this unit on.
5
Set the TV to the correct Video IN channel. (eg. EXT1,
EXT2, AV1, AV2, AUDIO/VIDEO, etc. (Refer to your TV
owner’s manual for detail)
➜
The front display lights up and the default screen
appears on the TV.
Smart Power On/Off
When in STOP mode, the DVD player will switch to
standby mode after 15 minutes without any operations
for saving energy. It is easily reactivated by pressing the
POWER or PLAY on the remote control or the
STANDBY/ON button on the front panel.
+
-
+
-
DVD
VCD
NTSC NTSC
NTSC
NTSC
NTSC
NTSCPAL
PAL
NTSC
PAL
PAL
PAL
PAL
PAL
NTSC
PAL
Type Format
Disc
Output format
Selected mode
NTSC PAL MULTI
Preparation
SL100_U2_eng Page 7 Friday, November 28, 2003 2:32 PM
