Yamaha DVD-S2500 [27/36] Audio cd
![Yamaha DVD-S2500 [27/36] Audio cd](/views2/1041391/page27/bg1b.png)
23
English
Operation
• Audio CDs contain only TRACKS.
• They can be played on this unit with the audio output
connected to a stereo system or to your TV.
• Select tracks using the track list on the TV screen or by
pressing the numerical buttons or kn buttons.
Disc structure
Playing a disc
1 Insert the disc and close the tray.
➜ Playback starts automatically.
➜ The TV screen will display the track list and current
playing status.
2 Playback will stop at the end of the disc.
3 To stop playback, press STOP.
Current VCD 2.0 and Super Video CD 1.0 standard
features include:
• Video CDs may contain one or more tracks, and tracks
may contain one or more indexes.
• You can display either tracks or indexes.
Disc structure
The following VCD and SVCD features and
formats are supported:
The following formats are not supported for
VCDs:
– HQ-VCD encoded at 2.4Mbps or 2.6Mbps
– XVCD (eXtended VCD) with higher resolution and
data rate
– DIVX format files
Playing a disc
1 Insert the disc and close the tray.
➜ Playback starts automatically.
➜ The current track number and its elapsed playing time
are displayed in the status window.
2 Playback will stop at the end of the disc.
3 To stop playback, press STOP.
Notes:
– The Disc Resume feature is also available for VCDs
and SVCDs (see the “Smart Resume” section on
page 20).
– When you play a Karaoke disc, you can change the
vocal by pressing AUDIO on the remote control.
Playback Control (PBC)
Playback Control is a feature on some Video CDs and
Super Video CDs that enables users to access selected
tracks directly from the disc menu.
1 Insert a Video CD or Super Video CD that features PBC,
then press PLAY.
2 Navigate the menu using the buttons indicated on the
TV screen until your chosen passage starts to play. If a
PBC menu displays a list of tracks, you can select a track
directly.
3 Enter your choice using the numerical buttons (0-9).
4 Press RETURN/RESUME or b to return to the
previous menu. Press a to proceed to the next menu.
5 You may also select [PBC OFF] in the On-screen menu.
➜ When [PBC OFF] is selected, PBC menus are
unavailable.
Audio CD
Video CD and
Super Video CD
CD
TRACK 1
TRACK 2
TRACK 3
VCD
TRACK 1 INDEX 1
INDEX 2
INDEX 3
TRACK 2
INDEX 1
INDEX 2
INDEX 3
Features Video CDs 2.0 Super Video CDs 1.0
Video
bit rate
resolution NTSC
resolution PAL
MPEG-1
constant 1,150 Kbps
352x240, 29.97Hz
352x288, 25Hz
MPEG-2
variable up to 2.6 Mbps
480x480 interlaced,
29.97Hz
480x576 interlaced, 25Hz
Still picture (photo)
resolution NTSC
resolution PAL
MPEG-1
352x240, 704x480
352x288, 704x576
MPEG-2 (1 Frame)
480x480, 704x480
480x576, 704x576
Audio
sampling
bit rate
audio channels
surround sound
MPEG-1 layer II
44.1KHz
224Kbps
1 stereo / 2 mono
Stereo with Dolby Pro-
Logic
MPEG-1 layer II
44.1KHz
32-384Kbps
< 2 stereo / 4 mono
MPEG-1 (5+1) extension
Overlay graphics/text
sub-channels
coding
overlay video plane
<= 4
4 color CLUT (2bits/pixel)
