Yamaha DVD-S2500 [35/36] Specifications
![Yamaha DVD-S2500 [35/36] Specifications](/views2/1041391/page35/bg23.png)
31
English
Specifications
PLAYBACK SYSTEM
DVD-Audio
DVD-Video
Super Audio-CD, Stereo/Multi-channel and Hybrid disc
DVD+R, DVD+RW
DVD-R, DVD-RW (Video Format)
Video CD (VCD)
Super Video CD (SVCD)
CD-Audio (CD-DA)
CD-R/CD-RW (CD-DA, VCD, SVCD)
MP3, JPEG
TV STANDARD (PAL/50 Hz) (NTSC/60 Hz)
Number of lines 625 525
Playback Multistandard (PAL/NTSC)
VIDEO PERFORMANCE
YUV output Y: 1Vpp into 75 ohm
Pb/Cb Pr/Cr: 0.7Vpp into 75 ohm
S-Video output Y: 1Vpp into 75 ohm
C: 0.3Vpp into 75 ohm (PAL)
C: 0.286Vpp into 75 ohm (NTSC)
Video output 1 Vpp into 75 ohm
AUDIO FORMAT
DSD Multi-channel and Stereo
Dolby Digital/DTS/MPEG Compressed Digital
PCM/Packed PCM fs 48, 96, 192, and 44.1, 88.2,
176.4kHz
16, 20, 24bits
MP3 (ISO9660) 32, 44.1, 48, and 16, 22.05, 24kHz
Full decoding of Dolby Digital, DTS and MPEG multi-channel
sound/analogue stereo sound
Dolby Surround compatible downmix from Dolby Digital multi-
channel sound
3D Sound for virtual 5.1 channel sound on two speakers
Dolby Pro Logic II 5.1 ch decoding from the stereo source
SA-CD AUDIO PERFORMANCE
D/A Converter DSD
SA-CD fs 2.8224 MHz
Max. output voltage (0 dB) 2 V rms
Signal-Noise Ratio 115 dB
Dynamic Range 107 dB
Total Harmonic Distortion (1 kHz) 0.0017 %
AUDIO PERFORMANCE (Without upsampling)
DA Converter 24 bits
DVD fs 96 kHz 2 Hz - 44 kHz
CD/Video CD fs 44.1 kHz 2 Hz - 20 kHz
Signal-Noise Ratio 115 dB
Dynamic Range 103 dB
(DVD 48 kHz 24 bit)
Total Harmonic Distortion (1 kHz) 0.0017 %
(DVD 48 kHz 24 bit)
CONNECTIONS
SCART Euroconnector x1 (Europe model
only)
Y Pb/Cb Pr/Cr Cinch 3x (green, blue, red)
S-Video Output Mini DIN, 4 pins
Video Output Cinch (yellow) x1
Audio Mixed 2 ch Output Cinch (white/red)
Digital Output 1 coaxial, 1 optical
6 channel analogue output
Audio Main L/R Cinch (white/red)
Audio Surround L/R Cinch (white/red)
Audio Centre Cinch (blue)
Audio Subwoofer Cinch (black)
HDMI TYPE A x1
IEEE1394 4 pins x2
CABINET
Dimensions (w x h x d) 435 x 100 x 314 mm
Weight Approx. 5.6 kg
POWER SUPPLY
Power inlet
U.S.A and Canada models AC120V, 60 Hz
Australia model AC240V, 50 Hz
U.K. and Europe models AC230V, 50 Hz
General model AC110-240V, 50/60 Hz
Power usage Approx. 33 W
Power usage standby < 1 W
Specifications subject to change without notice.
