TL-WN727N Wireless N USB Adapter User Guide

- 12 -

¾ - Back to the previous page.

¾ - Continue to the next page.

¾ Profile Name - Identifies the configuration profile. This name must be unique. Profile names

are not case-sensitive.

¾ SSID - The IEEE 802.11 wireless network name. This field has a maximum limit of 32

characters.

¾ Network Type: There are basically two modes of networking:

• Infrastructure - All wireless clients will connect to an access point or wireless router.

• Ad Hoc - Directly connecting to another computer, for peer-to-peer communication,

using wireless network adapters on each computer, such as two or more TL-WN727N

wireless adapters.

)

Note:

1) An Infrastructure network contains an Access Point or wireless router. All the wireless

devices or clients will connect to the wireless router or access point.

2) An Ad Hoc network contains only clients, such as laptops with wireless desktop adapters. All

the adapters must be in Ad Hoc mode to communicate.

2. In the following screen, select the corresponding Authentication mode and Encryption type

of the profile from the drop-down lists (here takes WPA2-PSK and AES for example), then

click the Next icon

to continue.

Figure 3-5 Authentication and Encryption

¾ Authentication - You can choose the Authentication Type from the pull-down list with

seven options, Open, Shared, WPA, WPA-PSK, WPA2, WPA2-PSK, and 802.1X.

¾ Encryption - Displays which encryption type that the adapter is using. When you select

Open as Authentication, there are two options: None and WEP. If you select Shared and

802.1X as Authentication, there is only one option: WEP. When you select WPA,

WPA-PSK or WPA2-PSK as Authentication, there are two options: TKIP and AES. When

you select WPA2 as Authentication, four options are available: TKIP, AES, TKIP(MFP) and

AES(MFP).
