TL-WN727N Wireless N USB Adapter User Guide
- 22 -
¾ Network Type - The type of network and the station currently connected are shown here.
The options include:
• Infrastructure (access point)
• Ad Hoc
¾ Central Channel - The channel of the currently connected AP.
Click the Throughput icon
, you can view the Link Quality, Signal Strength and Link Speed to
see whether the Adapter is working well.
Figure 3-27 Throughput
¾ Link Quality - Displays connection quality based on signal strength and TX/RX packet error
rate.
¾ Signal Strength - This shows the strength of the signal.
¾ Link Speed - Shows current transmit rate and receive rate.
¾ Throuhput - Displays transmit and receive throughput in unit of Mbps.
When clicking the Statistics icon
, you will see the following screens respectively displaying
the receiving and transmitting statistical information. Click the Reset Counter icon
to reset all
the counters to zero.
Figure 3-28 Transmit Statistics
¾ Transmitted Successfully - Frames successfully sent.
