TD-W8960N 300Mbps Wireless N ADSL2+ Modem Router User Guide

¾ Destination IP Address: The Destination IP Address is the address of the network or host

that you want to assign to a static route.

¾ Interface: Select the Interface name in the text box, or else, the default Use Interface will be

adopted for the Static Route.

¾ Gateway IP Address: If you select the IPoE or IPoA mode for Interface, the screen above

will display this item, you should type the Gateway address correctly, and the other option for

Interface will adopt the default Gateway address for the Static Route.

3. Click Save/Apply to and then you will see you settings as shown in Figure 4-51.

To remove a static rout

ing entry:

1. Select the Remove check box according to the entry in the Figure 4-51.

2. Click

the Remove button, and the entry will be deleted.

)

Note:

Gateway IP address should be correctly configured if IP based Interface (IPoE, IPoA) is selected.

4.4.10.3 RIP

Choose “Ad

vanced Setup”Æ“Routing”Æ“RIP”, you can see the RIP (Routing Information

Protocol) screen which allows you to configure the RIP (shown in Figure 4-53).

Figure 4-53

)

Note:

RIP cannot be configured on the WAN Interface which has NAT enabled (such as PPPoE).

To activate RIP for the device, configure an individual interface, select the desired RIP version and

operation, and select Enabled checkbox for the interface.

Click Save/Apply to save the configuration.

4.4.11 DNS

When you select the connection type PPPoE, PPPoA or IPoA for WAN configuration, you will see

the DNS menu in the Web-based Utility (shown in Figure 4-54). It includes DNS Server and

Dynamic DNS submenus.
