TD-8817 ADSL2+ Modem Router User Guide

given IP address provided by your ISP. For Static IP, you need to specify the IP address,

Subnet Mask and Gateway IP address.

¾ Default Route: You should select Yes to configure the PVC as the default gateway to

internet from this device.

¾ MAC Spoofing: MAC Spoofing feature allows you to change the assigned MAC address of

the ADSL Router to a different one, which may allow the bypassing of access control lists on

servers either hiding a computer on a network or allowing it to impersonate another computer.

You can select Enable and specify a MAC Address for the Router here, or keep the default

setting as Disable.

4. Bridge Mode

If you select this type of connection, the modem can be configured to act as a bridging device

between your LAN and your ISP. Bridges are devices that enable two or more networks to

communicate as if they are two segments of the same physical LAN.

Figure 4-10

)

Note:

After you finish the Internet configuration, please click SAVE to make the settings take effect.

4.3.2 LAN

Choose “Interface Setup→LAN” menu, and you will see the LAN screen (shown in Figure 4-11).

Please configure the parameters for LAN ports according to the descriptions below.
