TD-8616 ADSL2+ Modem User Guide

Appendix A: Specifications

General

Standards and Protocols

ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, G.992.4, ITU

G.992.5, IEEE 802.3, IEEE 802.3u, TCP/IP, HTTP

Safety & Emission FCC, CE

Ports

1 10/100M Auto-Negotiation RJ45 port（Auto MDI/MDIX)

1 RJ11 port

LEDs Power, LAN, ADSL, Internet

Network Medium

10Base-T: UTP category 3, 4, 5 cable

100Base-TX: UTP category-5

Max line length: 6.5Km

Data Rates

Downstream: Up to 24Mbps

Upstream: Up to 3.5Mbps（With Annex M enabled）

System Requirement

Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later

Win 9x/ME/2000/XP/Vista

Physical and Environment

Working Temperature 0℃ ~ 40℃

Working Humidity 10% ~ 90% RH (non-condensing)

Storage Temperature -40℃ ~ 70℃

Storage Humidity 5% ~ 90% RH (non-condensing)
