To preserve your compact discs, please handle them with care.
Although minute dust particles and fingerprints should have no effect on play
back, you should keep the serface of the recorded side of your discs clean by
wiping the disc with a clean, dry, lintfree soft cloth with straight movements
from the centre outwards.
Never use record cleaners, record sprays, antistatic sprays, liquids or chemical
based liquids to clean the surface of a disc. They may in fact irreparably damage
the disc's plastic surface.
Always return the disc to its protective plastic case when not using it. Avoid
exposing discs to direct sunlight, excessive temperatures or high humidity for
extended periods of time.
Do not write on the label side of the disc with a ball/point pen as this may scratch
the disc.
SPECIFICATIONS
Audio
D/A conversion 1bit DAC eight times oversampling
Frequency response 2020,000Hz
Antishock 45 seconds memory
Wow and flutter Below measurable limits
No. of channels 2 channels (stereo)
Output level Line output: 0.6V rms (47KW)
Headphone: 20mW (32W)
Bass Boost effect (100Hz) + 6dB
General
Power requirements 2 x 1.2V/NiMH Battery (Rectangular type)
DC in 4,5V jack accepts AC power adaptor
(centre positive)
Power consumption 0.8 W (DC 3V)
Dimension Approx. 132 (W) x 19 (H) x 136 (D) mm
Weight (without batteries) 200 g.
Note:
Specifications and the design are subject to possible modifications with
out notice due to improvement.
SERVICE LIFE OF THE
CD PLAYER NOT LESS THAN 3 YEARS
ENGLISH
7
8
КНОПКИ И ИХ ФУНКЦИИ
1. Кнопка ПРОГРАММА
2. Кнопка ВОСПРОИЗВЕДЕНИЕ/РЕЖИМ
3. Кнопка ПРОПУСТИТЬ/ПОИСК назад
4. Кнопка ПРОПУСТИТЬ/ПОИСК вперед
5. Кнопка СТОП (Автоматическое
отключение питания)
6. Кнопка ВОСПРОИЗВЕДЕНИЕ/ПАУЗА
(автоматическое включение питания)
7. LCD дисплей
8. Кнопка открытия крышки отсека для CD
9. Гнездо питания постоянного тока 4,5 В
10. Линейный выход
11. Гнездо для НАУШНИКОВ
12. Регулятор ГРОМКОСТИ
13. Переключатель ФУНКЦИИ УСИЛЕНИЯ
НИЗКИХ ЧАСТОТ
14. Кнопка АНТИШОК
15. Переключатель ЗАРЯДКИ
16. Индикатор ЗАРЯДКИ
17. Кнопка БЛОКИРОВКИ КЛАВИШ
18. Отсек для БАТАРЕЕК
19. Гнездо для ПУЛЬТА
ДИСТАНЦИОННОГО УПРАВЛЕНИЯ
РУССКИЙ
3785.qxd 04.03.04 14:53 Page 16
Содержание
- Инструкция по эксплуатации manual instruction 1
- Модель vt 3785 1
- English 2
- Русский 2
- Battery charging 1 open the battery compartment door 2 insert 2 rechargeable ni mh batteries 1 v 1200mah rectangular type following the correct polarity as indicated on the unit 3 close the battery compartment door 4 attach the adaptor to socket 9 and connect to wall outlet 5 move the charge switch 15 to on to start recharging function the red charge indicator 16 will light indicating that the rechargeable batteries are being charged 6 after 15 hours of charging unplug the adaptor from the wall outlet 3
- Cautions 3
- Do not mix the rechargeable ni mh and regular carbon zinc batteries 3
- English 3
- If the ac adaptor is connected when the batteries are installed the power sup ply automatically switches to the ac power source use only the supplied ac dc adaptor using other types of adaptor may dam age the unit make sure that the ac dc adaptor matches with your household voltage before connecting it into the wall outlet when not using ac power disconnect the ac dc adaptor from the wall outlet do not touch the ac dc adaptor with wet hands 3
- Power supply use with ac dc adaptor included 1 insert the dc plug at the end of the ac dc adaptor cord into the dc 4 v input socket 9 of the unit 2 connect the ac dc adaptor into a 230v 50hz ac power outlet 3
- Русский 3
- Cd playback 1 connect the earphones included or optional headphones into the phones jack 4
- Connections external audio system connect the stereo connection cable not included into the line out jack 10 of the unit and the cd aux of the audio system do not connect it to the ampli fier phone jack 4
- Do not charge continuously for 24 hours or more otherwise it will deteriorate the performance of the rechargeable batteries 4
- Earphones with inline remote control connect the stereo earphones included to the phones socket 11 then con nect the inline remote control jack into the inline remote control socket 19 of the unit 4
- English 4
- If the rechargeable batteries are being charged for the first time it will take approximately 15 hours to be fully charged if the operating time decreases drastically even when the rechargeable bat teries are properly recharged you need to purchase a new set of rechargeable batteries 4
- Note always switch off the power before making any connections between the cd player and other audio system if the cd player interference with the tv or radio reception move the cd play er away from tv set or radio receiver 4
- Русский 4
- English 5
- Locating a particular track or point of the track 1 press the backward button once to go back to the beginning of the current track 2 press the backward button repeatedly to go back to previous tracks 3 press the forward button repeatedly to go to next tracks 4 press and hold either forward or backward button to search backwards or forwards at high speed a particular point of track 5
- Note low level audio will be heard during the search process to assist in locat ing the correct point in the track 5
- Press the door open button 8 to open the cd compartment door 3 insert a disc with the label side facing up 4 close the cd compartment door until a click is heard 5 set the volume control to minimum 6 press the play pause button 6 the unit power will turn on automati cally and starts playback the total number of tracks and playing time appears on the display during playback the track number and the elapsed playing time will be displayed 7 adjust the volume control to your desired listening level 8 to stop playback temporarily press the play pause button 6 once the elapsed time and track number will flash on the display press the play pause button again to resume playback 9 to stop playback press the stop 5 button once 10 to turn the unit off press the stop 5 twice 5
- Repeat playback 1 press the play pause button 6 2 to repeat the same track press the cd mode button 2 once the indicator 1 will appear on the display and starts single repeat playback until stop button 5 is pressed 3 to repeat the entire cd press the cd play mode button 2 twice during play back the indicator all will appear on the display and all tracks will be repeated to cancel the repeat mode simply press the stop button 5 the indicator disappears from the display 5
- When the cd door is accidentally opened during playback open will appear on the display wait until the disc is fully stopped before pressing the open button this unit can play 3 8cm single cds without an adaptor 5
- Русский 5
- English 6
- Русский 6
- English 7
- Русский 7
- English 8
- Русский 8
