Carrier 38AUZA07A0G9 [11/13] Auz d 50 hz
![Carrier 38AUDA25A0A9 [11/13] Auz d 50 hz](/views2/1427912/page11/bgb.png)
Domestic
Commercial Products
38AUZ/D – 50 Hz
COMMERCIAL SPLIT SYSTEMS
CONDENSING UNITS
18.3 kW TO 59.2 kW
Carrier Corporation • Syracuse, N.Y. 13221 F.O.B. SHIPPING POINT
SUBJECT TO CHANGE WITHOUT NOTICE FREIGHT AS PER D.O.M.
FIELD-INSTALLED ACCESSORIES (cont)
PAGE
11
REFRIGERANT SPECIALTIES - SIGHT GLASSES
Please refer to the Application Data section in the Product Data for refrigerant pipe sizing. A sight glass is recommended for all
commercial split systems.
L - Liquid Line
* RCD List Price - Subject to change on a quarterly basis and should be verified with RCD prior to quoting.
LOUVERED HAIL GUARDS – CONDENSER COIL
condenser coil from damage and vandalism
condenser coil from damage and vandalism
condenser coil from damage and vandalism
condenser coil from damage and vandalism
condenser coil from damage and vandalism
condenser coil from damage and vandalism
WIRED GUARDS – CONDENSER COIL
condenser coil from larger objects
condenser coil from larger objects
condenser coil from larger objects
condenser coil from larger objects
ORDERING DESCRIPTION USED ON
NUMBER
KM680008 Sight Glass All Liquid Lines 9.7 mm (3/8 inch)
KM680004 Sight Glass All Liquid Lines 13 mm (1/2 inch)
KM680005 Sight Glass All Liquid Lines 16 mm (5/8 inch)
ORDERING DESCRIPTION APPLICATION
NUMBER USAGE
CALVHLGD001A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 07 Models
CALVHLGD002A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 08 Models
CALVHLGD003A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 12 Models
CALVHLGD004A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 14 Models
CALVHLGD007A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 16 Models
CALVHLGD009A00 Louvered Condenser Coil Hail Guard -- Includes louvered panel(s) to protect 25 Models
ORDERING DESCRIPTION APPLICATION
NUMBER USAGE
CAGRILLE006A00 Wired Grille - Condenser Coil Guard -- Includes panel(s) to protect 07 Models
CAGRILLE007A00 Wired Grille - Condenser Coil Guard -- Includes panel(s) to protect 08 Models
CAGRILLE008A00 Wired Grille - Condenser Coil Guard -- Includes panel(s) to protect 12 Models
CAGRILLE009A00 Wired Grille - Condenser Coil Guard -- Includes panel(s) to protect 14 Models
