Carrier 38AUZA07A0G9 [12/13] Auz d 50 hz
![Carrier 38AUZA08A0G9 [12/13] Auz d 50 hz](/views2/1427912/page12/bgc.png)
Domestic
Commercial Products
38AUZ/D – 50 Hz
COMMERCIAL SPLIT SYSTEMS
CONDENSING UNITS
18.3 kW TO 59.2 kW
Carrier Corporation • Syracuse, N.Y. 13221 F.O.B. SHIPPING POINT
SUBJECT TO CHANGE WITHOUT NOTICE FREIGHT AS PER D.O.M.
FIELD-INSTALLED ACCESSORIES (cont)
PAGE
12
COMMERCIAL NON-COMMUNICATING THERMOSTATS
Debonair2 Debonair Slimline
Debonair FlatStat Corporate Stat
Debonair Wireless Thermostat
FEATURE HIGHLIGHTS:
• 1-For-All design - 4/5 wire - heat pump, G/E,
electric heat, hydronics
• Security keypad lockout and configurable access
levels
• Large, easy-to-read Thermoglow display, easy to
program
• 4 hour setback override, adjustable increments
• Autochangeover, 2 & 3 stage heat/2 stage cool
• Debonair2 and Flat thermostats include ExactFit
tamper-proof locking cover, with regular and
tamper-proof screws
• No mercury, no batteries (except wireless)
• Bright-white color and handsome designs
• Temperature calibration, adjustable timeguards,
deadband and temperature difference
• Programmable stats meet California Commercial
Title 24
• Auxiliary relay - signal to economizer
• External input to interface w/other building systems
• Heat/Cool Lockout
• Remote sensing
• Sensor average up to 16 remote room sensors
• Wireless and light-activated control
• Softstart up to 99 units
• 99 consecutive days Holiday schedule
THERMOSTATS
ORDERING
NUMBER
STYLE DESCRIPTION SENSORS
33CSSN2-WC Debonair2 Debonair Std. Non-Prog., 2 stg. ht/cl, G/E & HP (w/ExactFit Locking
Cover).
None
33CSSP2-WC Debonair2 Debonair Std. Prog., 2 stg ht/cl, G/E & HP (w/ExactFit Locking Cover). None
33CS400-01 Slimline Debonair 400 - Non-Programmable, 2-stage Heat/Cool, HP or G/E,
Manual Changeover, 3 configurable outputs, remote contact input,
Remote Sensor Capable.
Remote,
Duct,
Outdoor
33CS420-01 Slimline Debonair 420 - 7-Day Programmable/Non-Prog. 3-stage Heat/2-stage
Cool, HP or G/E, Manual/Auto-Changeover, Low/Hi outdoor Temp.
Outdoor
33CS450-01 Slimline Debonair 450 - Premier 7-Day Programmable/Non-Prog., 3-stage
Heat/2-stage Cool, HP or G/E, Remote Contact Input, Remote Sensor
Capability, Pre-Occupancy Purge, Soft Start, Manual/Auto-
Changeover, Economizer Output Signal, Reheat Capable, Low/Hi
Outdoor Temp, Light Activated.
Remote,
Duct,
Outdoor
