![Carrier 38AUZA07A0G9 [13/13] Auz d 50 hz](/views2/1427912/page13/bgd.png)
Domestic
Commercial Products
38AUZ/D – 50 Hz
COMMERCIAL SPLIT SYSTEMS
CONDENSING UNITS
18.3 kW TO 59.2 kW
Carrier Corporation • Syracuse, N.Y. 13221 F.O.B. SHIPPING POINT
SUBJECT TO CHANGE WITHOUT NOTICE FREIGHT AS PER D.O.M.
FIELD-INSTALLED ACCESSORIES (cont)
PAGE
13
ORDERING
NUMBER
STYLE DESCRIPTION SENSORS
33CS220-FS Flat Debonair 7-Day Programmable, 2 stg ht/cl, HP, G/E, Auto-Changeover
w/ExactFit locking cover - fits standard 2x4 Junction Box.
None
33CS250-FS Flat Debonair 7-Day Programmable, 2 stg ht/cl, G/E, HP, Auto-
Changeover, w/ExactFit Locking Cover - fits standard 2x4 Junction
Box - remote Sensor Capable, Pre-occ. Purge and Soft Start.
Remote,
Duct
33CS250-RC Wireless Debonair 250 Wireless Thermostat, 7-Day Programmable, 2-stage
Heat/Cool, HP or G/E, Pre-Occupancy Purge and Auto-Changeover.
None
33CS250-RE Wireless Debonair 250 Wireless Receiver - Must be used with Part No.
33CS250-RC.
None
THERMOSTAT ACCESSORIES
33CSSEN-WB Remote Room Sensor with Push Button Override, Used
on 33CS450-01 and 33CS400-01
33CS400-01, 33CS450-01,
33CS250-FS
33CSSEN-01 Remote Room Sensor without override. Outside Air
Temperature Sensor for the 33CS400-01 & 33CS450-01.
33CS400-01, 33CS450-01,
33CS250-FS
33CSSEN-DS Duct Temperature Sensor 33CS400-01, 33CS450-01,
33CS250-FS
33CSRFS-1RC Wireless Remote Room Sensor Transmitter - Can use
up to 8 in any combination - provides Sensor Averaging
capability; use with 33CSRFS-1RE
33CS400-01, 33CS450-01,
33CS250-FS
33CSRFS-1RE Wireless Remote Room Sensor Receiver; use with
33CSRFS-1RC
33CS400-01, 33CS450-01,
33CS250-FS
33CSACC-BP Decorator Backplates for Debonair (package of 2 - 2
sizes)
33CS400-01, 33CS420-01,
33CS450-01
33CSDOR-SS FlatStat stainless steel door/cover for schools 33CS220-FS, 33CS250-FS
33CSDOR-FS Replacement Doors 33CS220-FS, 33CS250-FS
33CSDOR-D2 Replacement Doors 33CSSN2/SP2-WC
ZONECC0RRS01 Remote Room Sensor 33CS2PP2S-01, 22CS2PPRH-
01
TSTATXXSEN01-B Outdoor Temperature Sensor 33CS2PP2S-01, 22CS2PPRH-
01
33CSACC-AW Add a Wire Any 24 VAC stat with more than
2 wires
33CSACC-AZ Add a SubZone Any 24 VAC thermostat, and
Comfort Zone Damper
33CSACC-DR Replacement Doors 33C400-01, 33CS420-01,
33CS450-01
ORDERING DESCRIPTION FITS MODE
NUMBER
