1
Introduction
XWWarning
To prevent possible electrical shock, fire, or personal injury,
read all safety information before you use the Product.
The Fluke 709, 709H, and 710 Precision Loop Calibrator (the Product or the Calibrator)
can be used for installation, calibration, and troubleshooting of field transmitters, valves,
and other control system components at process plants. Primary functions are source
and measure mA signals in the 0 mA to 24 mA range. The Product can measure 0 V to
30 V and produce 24 V dc loop power.
The 709H includes HART communication functionality and supports a select set of HART
universal and common-practice commands. The Product can be used as a loop calibrator
or basic function communicator.
The 710 has all the functions of the 709H plus test functions for HART smart control
valves.
This manual explains how to verify the Product functions and how to adjust Product
Calibration. For usage information, see the 709/709H/710 Users Manual.
Note
All figures in this manual show the 709H.
Contact Fluke
To contact Fluke, call one of the following telephone numbers:
• Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
• Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31 402-675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• China: +86-400-921-0835
•
Brazil: +55-11-3530-8901
• Anywhere in the world: +1-425-446-5500
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
