5. USE STATIC SHIELDING CONTAINERS FOR

HANDLING AND TRANSPORT.

6. DO NOT SLIDE S.S. DEVICES OVER

ANY SURFACE.

7. AVOID PLASTIC,VINYL AND STYROFOAM



IN WORK AREA.

8. WHEN REMOVING PLUG-IN ASSEMBLIES

HANDLE ONLY BY NON-CONDUCTIVE

EDGES AND NEVER TOUCH OPEN EDGE

CONNECTOR EXCEPT AT STATIC-FREE

WORK STATION. PLACING SHORTING

STRIPS ON EDGE CONNECTOR HELPS

PROTECT INSTALLED S.S. DEVICES.

9. HANDLE S.S. DEVICES ONLY AT A

STATIC-FREE WORK STATION.

10. ONLY ANTI-STATIC TYPE SOLDER-

SUCKERS SHOULD BE USED.

11. ONLY GROUNDED-TIP SOLDERING

IRONS SHOULD BE USED.

PORTIONS REPRINTED

WITH PERMISSION FROM TEKTRONIX INC.

AND GERNER DYNAMICS, POMONA DIV.

 Dow Chemical
