24
Fluke 719Pro
Electric Pressure Calibrator
The Fluke 719Pro Electric Pressure
Calibrators with onboard electric
pump makes pressure calibration
easy; at the touch of a button.
The 719Pro also includes a full
functioning loop calibrator that
sources, simulates and measures
mA signals. Best-in-class accuracy
makes the 719Pro the ideal tool
for testing high accuracy pressure
transmitters with high confidence.
Key features:
• Unique integrated electric pump for one handed
pressure calibration
• Test pressure switches easily with easy-to-use
switch test function
• The large backlit screen displays three
measurement or source parameters at once
– Pressure measurement from internal
or external sensor
– Sourced/simulated or measured mA values
– Temperature measured by optional RTD probe
• Precision vernier for easy and accurate pressure
adjustments
• Programmable pressure calibrator pump limit:
eliminates over-pressurization
• Pump cleanout ports reduce pump failures from
moisture and fluid damage
• Fluid trap included to mitigate fluid damage in
at-risk applications
• 3-year warranty
Summary specifications:
• 30 psi, 150 psi and 300 psi pressure ranges
• 6-month total uncertainty of 0.025%, 0.035% for
1 year
• Temperature measurement from -50 to 150 °C
(with optional 720 RTD probe)
Application coverage:
• High accuracy reference class
pressure transmitters
• Pressure switches
• Pressure gauges
• I to P converters
• Measure or generate 4 to 20 mA
• Measure 0 to 30 V dc
• Compatible with Fluke 750P Series
Pressure Modules
3130 Portable
Pressure Calibrator
Everything you need to provide an accurate steady
pressure, and read the output of the device under
test at the bench or in the field.
Use the internal pump for easy pressure or
vacuum generation or connect to an external
pressure supply for fast
calibration with larger
volumes. Built-in electrical
measurement capability
and rugged carrying case
makes it ideal for calibrating
pressure transmitters,
and pressure
switches at the
bench or in
the field.
Key features:
• Button press to generate pressure and vacuum
with internal pump
• Includes variable volume for fine adjustment of
pressures
• Internal 24 V loop power supply can power a
transmitter under test
• Measure or generate 4 to 20 mA signals
• Measure 0 to 30 V dc
• Powered by internal, high capacity,
NiMH battery
• Compatible with Fluke 700P and 750P Series
Pressure Modules
Summary specs
• Vacuum to -80 kPa (-12 psi, -0.8 bar)
• Pressure to 2 MPa (300 psi, 20 bar)
• Pressure measurement accuracy of 0.025 %
reading ± 0.01 % FS
Application coverage
• Pressure gauge calibration
• Pressure transmitter calibration
• Pressure switch test and calibration
Each unit includes
Four 1/8-inch NPT quick connectors for calibration
hoses, two 3-foot sections of 1/8-inch O.D hose.
One, 1/8-inch NPT female on 1/4-inch NPT female
fitting, One 1/8-inch BSP female fitting, Thread
seal tape, Test cables (two, red, two black), Univer-
sal power supply, Traceable calibration certificate,
Manual
