Using the Conguration Menu (continued)

Advanced > Firewall

Firewall Rules is an advanced feature used to deny or allow trafc from passing

through the DI-724P+. It works in the same way as IP Filters with additional settings.

You can create more detailed access rules for the DI-724P+. When virtual services

are created and enabled, it will also display in Firewall Rules. Firewall Rules contain

all network rewall rules pertaining to IP (Internet Protocol).

In the Firewall Rules List at the bottom of the screen, the priorities of the rules are

from top (highest priority) to bottom (lowest priority.)

Note:

The DI-724P+ MAC Address ltering rules have precedence over the Firewall Rules.

Firewall Rules-

Enable or disable the Firewall

Name-

Enter the name

Action-

Allow or Deny

Source-

Enter the IP Address range

Schedule-

Select Always or enter the Time Range.

Destination-

Enter the IP Address range; the Protocol;

and the Port Range
