Connections
Ethernet Port – this RJ-45
Auto MDI/MDIX port provides
connection to a network
device using a
Cat 5 Ethernet
cable. (The Auto
MDI/MDIX port
accommodates either a
Straight-Through or a Cross-
Over cable and is auto-
sensing.)
Reset Button –
press this button to revert to
the factory default settings of
the DWL-800AP+
Power Receptor – connect
one end of the 5V DC Power
Adapter (included) to the power receptor on the DWL-800AP+ and connect
the other end of the Power Adapter to a power outlet.
Factory Default Settings for the DWL-800AP+*
Wireless Mode Repeater
SSID default
Channel 6
Transmission rates Auto
Encryption No
Administrator password Blank (no password needed)
IP Address mode Static
IP Address 192.168.0.30
IP Subnet 255.255.255.0
username admin (all lower case)
Ethernet
Reset Button
Power Receptor
Category 5 is the most reliable grade of twisted-
p
air cable. It Is available as eithe
r
Straight-Through cable or Cross-Over cable. Always check your installation
instructions to make sure that you have selected the correct type of Category
5
cable for your other networking devices. The DWL-800AP+ will accept either type
of cable and will automatically sense the cable that you are using.
