GA-MA790GP-UD3H Motherboard - 40 -
Advanced Clock Calibratioin
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Clock Calibratioin
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
EC Firmware Selection [Normal]
Advanced Clock Calibratioin [Disabled]
x Value (All Cores) -2%
x Value (Core 0) -2%
x Value (Core 1) -2%
x Value (Core 2) -2%
x Value (Core 3) -2%
EC Firmware Selection
Allows you to select the EC firmware version when Advanced Clock Calibration is enabled.
After the selection, select Save & Exit Setup in the BIOS Main Menu and then press Y. A message
which says "BIOS Is Updating EC Firmware!!! Don't Turn Off Or Reset System" will appear.
Wait for a few seconds and the system will automatically restart for the settings to take effect.
Normal Uses the standard AMD EC firmware version. (Default)
Hybrid Uses the specific AMD EC firmware version.
Advanced Clock Calibration
Allows you to determine whether to enable Advanced Clock Calibration when using an AMD Black
Edition CPU.
Disabled Disables this function. (Default)
Auto Lets the BIOS to configure the settings to defaults.
All Cores Configures Advanced Clock Calibration for all CPU cores.
Per Core Individually configures Advanced Clock Calibration for each CPU core.
Value (All Cores)
This option is configurable only when Advanced Clock Calibration is set to All Cores.
Options are: -12%~+12%.
Value (Core 0), Value (Core 1), Value (Core 2), Value (Core 3)
This option is configurable only when Advanced Clock Calibration is set to Per Core.
Options are: -12%~+12%.
HT Link Frequency
Allows you to manually set the frequency for the HT Link between the CPU and chipset.
Auto BIOS will automatically adjust the HT Link frequency. (Default)
200 MHz~1 GHz Sets HT Link Frequency to 200 MHz~1 GHz.
(Note) This item is present only if you install a CPU that supports this feature.
