GA-MA790GP-UD3H Motherboard - 46 -
2-5 Advanced BIOS Features
Internal Graphics Mode
Allows you to determine whether to allocate memory for the onboard graphics controller from the
system memory or SidePort memory
Disabled Disables the onboard graphics controller.
UMA Allocates memory for the onboard graphics controller from the system
memory.
SidePort Allocates memory for the onboard graphics controller from the SidePort
memory.
UMA+SidePort Allocates memory for the onboard graphics controller from the system
memory and SidePort memory. (Default)
UMA Frame Buffer Size
Frame buffer size is the total amount of system memory allocated solely for the onboard graphics
controller. MS-DOS, for example, will use only this memory for display. Options are: Auto
(default), 128MB, 256MB, 512MB.
Surround View
Enables or disables the Surround View function. This option is configurable only if an ATI graphics
card is installed. (Default: Disabled)
Onboard VGA output connect
Specifies the graphics display of the onboard VGA output from the D-SUB/DVI-D or D-SUB/HDMI.
Auto BIOS automatically determines the primary display port for output,
depending on to which port the display device is connected, D-SUB/DVI-D
or D-SUB/HDMI. (Default)
D-SUB/DVI Sets the D-SUB/DVI-D as the graphics display.
D-SUB/HDMI Sets the D-SUB/HDMI as the graphics display.
(Note) This item is present only if you install a CPU that supports this feature.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced BIOS Features
Internal Graphics Mode [UMA+SidePort]
UMA Frame Buffer Size [Auto]
x Surround View Disabled
Onboard VGA output connect [Auto]
Virtualization [Disabled]
Patch AMD TLB Erratum
(Note)
[Enabled]
AMD K8 Cool&Quiet control [Auto]
Hard Disk Boot Priority [Press Enter]
First Boot Device [Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Password Check [Setup]
HDD S.M.A.R.T. Capability [Disabled]
Away Mode [Disabled]
Full Screen LOGO Show [Enabled]
Backup BIOS Image to HDD [Enabled]
Init Display First [PCI Slot]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
