BIOS Setup - 40 -
(Note) This item appears only if you install a CPU that supports this feature.
Write Recovery Time
Options are: Auto (default), 5T~12T.
Precharge Time
Options are: Auto (default), 4T~7T.
Row Cycle Time
Options are: Auto (default), 11T~42T.
RAS to RAS Delay
Options are: Auto (default), 4T~7T.
Bank Interleaving
Enables or disables memory bank interleaving. Enabled allows the system to simultaneously access dif-
ferent banks of the memory to increase memory performance and stability. (Default: Enabled)
Channel interleave
Enables or disables memory channel interleaving. Enabled allows the system to simultaneously access
different channels of the memory to increase memory performance and stability. (Default: Enabled)
DQS Training Control
Enables or disables memory DQS training each time the system restarts. (Default: Skip DQS)
Memclock tri-stating
Determines whether to enable memory clock tri-stating in CPU C3 or Alt VID mode. (Default: Disabled)
********
System Voltage Optimized
********
System Voltage Control
Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the
system voltages as required. Manualallowsallvoltagecontrolitemsbelowtobecongurable.(Default:
Manual)
DDR3 Voltage Control
Allows you to set memory voltage.
Normal Supplies the memory voltage as required. (Default)
+0.100V ~ +0.300V The adjustable range is from +0.100V to +0.300V.
Note: Increasing memory voltage may result in damage to the memory.
NorthBridge Volt Control
Allows you to set the North Bridge voltage.
Normal Supplies the North Bridge voltage as required. (Default)
+0.1V ~ +0.3V The adjustable range is from +0.1V to +0.3V.
SouthBridge Volt Control
Allows you to set the South Bridge voltage.
Normal Supplies the South Bridge voltage as required. (Default)
+0.1V ~ +0.3V The adjustable range is from +0.1V to +0.3V.
