Gigabyte GA-MA78LMT-S2H [44/100] 5 advanced bios features
![Gigabyte GA-MA78LMT-S2H [44/100] 5 advanced bios features](/views2/1045030/page44/bg2c.png)
BIOS Setup - 44 -
(Note) This item appears only if you install a CPU that supports this feature.
2-5 Advanced BIOS Features
j
Only for GA-MA78LMT-S2H
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced BIOS Features
IGXConguration [PressEnter]
AMD C1E Support
(Note)
[Disabled]
Virtualization [Disabled]
Patch AMD TLB Erratum
(Note)
[Enabled]
AMD K8 Cool&Quiet control [Auto]
Hard Disk Boot Priority [Press Enter]
First Boot Device [Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Password Check [Setup]
HDD S.M.A.R.T. Capability [Disabled]
Away Mode [Disabled]
Backup BIOS Image to HDD [Disabled]
Init Display First [PCI Slot]
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Clock Calibration
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Internal Graphics Mode [UMA]
UMA Frame Buffer Size [Auto]
x Surround View Disabled
Onboard VGA output connect
j
[D-SUB/DVI]
VGA Core Clock control [Disabled]
x VGA Core Clock(MHz) 350
IGX Conguration
Internal Graphics Mode
Allows you to determine whether to allocate system memory for the onboard graphics controller.
Disabled Disables the onboard graphics controller.
UMA Allocates memory for the onboard graphics controller from the system memory.
(Default)
