EN
Function Power
Use this function to accelerate heating. The function
Power allows to increase power of a heating zone.
4 cooking zones:
By activation the function Power for the cooking zone 9
a level of heating of the zone 10 will be reduced to level
2 and vice versa.By activation the function Power for
the cooking zone 11 a level of heating of the zone 12
will be reduced to level 2 and vice versa.
3 cooking zones:
By activation the function Power for the cooking zone
13 a heating level of the zone 14 will be reduced to
level 2, a heating level of the zone 15 will be limited
under level 9.
By activation the function Power for the cooking zone
14 a heating level of the zone 13 will be reduced to
level 2, a heating level of the zone 15 will be limited
under level 9.
By activation the function Power for the cooking zone
15 a heating level of the zone 14 will be reduced to
level 9, a heating level of the zone 13 will be limited
under level 2.
• Choose by touching the keys 1, 2, 3, or 4 a
cooking zone you need.
The indication of the heating level of the corresponding
heating zone blinks.
• Choose a heating level you need by touching the
keys 5 and 6 (+ und –).
• Touch the key 7, Power.
The display of the corresponding cooking zone shows a
symbol 8, P. The function Power is activated.
The function Power function will be automatically
switched off in 5 minutes after its activation. The heating
levels of the cooking zones are returning to the previous
settings.
• To deactivate the function Power ahead of time,
touch a key of a corresponding cooking zone of 1,
2, 3 or 4 and then the key 7 or the key 6 ( –).
4
1
3
7 6 52
8
Cooking zone
Kochzone
Нагревательное поле
Maximal power, W
Maximale Leistung, W
Максимальная мощность, Вт
Normal
Normale
Нормальная
Increased
Erhöht
Повышенная
9
10
11
12
13
14
15
9
1500
2000
10
2200
2900
11
2000
2800
12
1500
2000
13
1500
2000
14
2100
2900
15
3600
5000
36
