DI-304/DI-304M ISDN Remote Router

Installation & Setup

Before You Start

♦ Use only the power adapter supplied by D-Link Corporation (18 VAC 1A).

Using an incorrectly rated power adapter will result in damage to the router.

♦ Know the type of interface provided by your ISP or telecom. The standard model

only supports the ISDN BRI S/T-interface. If you are an ISDN U-interface user,

you need to order a U-interface model. If you are an ISDN S/T-interface user,

you should have an NT-1 or NT-1 plus provided by your ISP or telecom. Also,

make sure the ISDN line is available.

♦ In case of emergency, unplug the power adapter first.

♦ Locate the device in a clean location. Do not block the ventilating slots on the

rear panel.

♦ Cables must be attached to the correct ports; to do otherwise may result in

damage to the router. Keep cables away from walkways.

♦ If you use S/T-interface, do not extend the ISDN line greater than 100 meters

from the NT-1 (NT-1 plus) box and the router.

♦ If you use DSL/Cable, check that your subscribed DSL/Cable modem supports

the Ethernet interface for connecting to your PC. If not, you will be unable to

connect it to the router.

Ordering Your ISDN Line

If you do not have an ISDN line installed already, we suggest that you order it from

your telephone company as soon as possible to avoid the long waiting period

common when ordering a new line. Use the information in this section to place the

order. If you have already installed your ISDN line, you can check the following

section to make sure that you can use all the features of your DI-304/DI-304M.

1. Contact your local telephone company’s ISDN Ordering Center.

2. Make sure DSS1 switches are available since these are the only switch types

currently supported by the DI-304/DI-304M.

3. When the telephone company installs your ISDN line, be sure to obtain the

following information:

◊ ISDN switch type.

◊ ISDN telephone number(s).
