- 11 - Hardware Installation
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
1xoppydiskdriveconnector
1 x IDE connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In/Out header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x clearing CMOS jumper
Back Panel
1 x PS/2 keyboard/mouse port
Connectors
1 x D-Sub port
1 x DVI-D port
(Note 2) (Note 3)
1 x HDMI port
j
(Note 3)
8 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller
iTE IT8718 chip
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU fan speed control
(Note 5)
BIOS
2x8Mbitash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
j
Only for GA-MA74GM-S2H
