Gigabyte GA-MA74GM-S2 (rev.4.1) [38/100] Dram configuration
![Gigabyte GA-MA74GM-S2 (rev.4.1) [38/100] Dram configuration](/views2/1045280/page38/bg26.png)
BIOS Setup - 38 -
DCTs Mode
(Note)
Allows you to set memory control mode.
Ganged Sets memory control mode to single dual-channel.
Unganged Sets memory control mode to two single-channel. (Default)
DDRII Timing Items
ManualallowsallDDR2Timingitemsbelowtobecongurable.
Options are: Auto (default), Manual.
CAS# latency
Options are: Auto (default), 3T~7T.
RAS to CAS R/W Delay
Options are: Auto (default), 3T~6T.
Row Precharge Time
Options are: Auto (default), 3T~6T.
Minimum RAS Active Time
Options are: Auto (default), 5T~18T.
1T/2T Command Timing
Options are: Auto (default), 1T, 2T.
TwTr Command Delay
Options are: Auto (default), 1T~3T.
Trfc0 for DIMM1
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
Trfc2 for DIMM2
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
DRAM Conguration
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
DRAMConguration
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
DCTs Mode
(Note)
[Unganged]
DDRII Timing Items [Auto] SPD Auto
x CAS# latency Auto 5T 5T
x RAS to CAS R/W Delay Auto 5T 5T
x Row Precharge Time Auto 5T 5T
x Minimum RAS Active Time Auto 15T 15T
x 1T/2T Command Timing Auto -- --
x TwTr Command Delay Auto 3T 3T
x Trfc0 for DIMM1 Auto 105ns 105ns
x Trfc2 for DIMM2 Auto -- --
x Write Recovery Time Auto 5T 5T
x Precharge Time Auto 3T 3T
x Row Cycle Time Auto 21T 21T
x RAS to RAS Delay Auto 3T 3T
CKE Power Down Mode [Disabled]
(Note) This item appears only if you install a CPU that supports this feature.
